PG2-5 INTRODUCTION
Warranty
Fireplace Dimensions
Installation Overview
General Instructions
General Information
Care of Glass
6-11 VENTING
Vent lengths
Venting Specifi cations
Minimum Air Terminal Location Clearances
12-18 INSTALLATION
Wall & Ceiling Protection
Horizontal Installation
Vertical Installation
Using Flexible Vent Components
Horizontal Air Terminal Installation
Vertical Air Terminal Installation
Fireplace Vent Connection
Using Rigid Vent Components
Horizontal Air Terminal Installation
Extended Horizontal Air Terminal Installation
Vertical Air Terminal Installation
Mobile Home
Gas Installation
Restricting Vertical Vents
Minimum Framing Clearances
Minimum Enclosure Clearances
Minimum Mantel and Enclosure Clearances
18 ELECTRICAL CONNECTION
Hard Wiring Connections
Electrical Schematic
19-20 FINISHING
Door Removal
Log Shipping Bracket
Decorative Brick Panel Installation
Log Placement
Glowing Embers
AFK / WI FACE KIT Installation
21-22 SERVICING / REPLACEMENTS
Glass / Door Replacement
Blower Replacement
Burner and Valve Replacement
Spark Module Battery Replacement
Night Light TM Replacement
22-24 OPERATION
Fireplace Operation
Hand Held Remote Operation
Operating Instructions
25 OPERATING INSTRUCTIONS
26
ADJUSTMENTS
Maintenance
Pilot Burner Adjustment
Flame Characteristics
Venturi Adjustment
27-28 REPLACEMENTS
Ordering Replacement Parts
Replacement Parts
Flexible Vent Kits
Terminal Kits
Roof Terminal Kits
Accessories
29-30 TROUBLE SHOOTING GUIDE
31
FIREPLACE SERVICE HISTORY
32 NOTES
TABLE of CONTENTS
PLEASE RETAIN THIS MANUAL FOR FUTURE REFERENCE
NOTE: Changes, other than editorial, are denoted by a vertical line in the margin.
• Do not burn wood or other materials in this fireplace.
• Adults and especially children should be alerted to the hazards of high surface temperatures and should stay away to avoid
burns or clothing ignition. Supervise young children when they are in the same room as the fireplace.
• Clothing or other flammable material should not be placed on or near the fireplace.
• Due to high temperatures, the fireplace should be located out of traffic and away from furniture and draperies.
• Ensure you have incorporated adequate safety measure to protect infants/toddlers from touching hot surfaces.
• Even after the fireplace is out, the glass and/or screen will remain hot for an extended period of time.
• Check with your local hearth specialty dealer for safety screens and hearth guards to protect children from hot surfaces. These
screens and guards must be fastened to the floor.
• Any safety screen or guard removed for servicing must be replaced prior to operating the fireplace.
• It is imperative that the control compartments, burners and circulating blower and its passageway in the fireplace and venting
system are kept clean. The fireplace and its venting system should be inspected before use and at least annually by a qualified
service person. More frequent cleaning may be required due to excessive lint from carpeting, bedding material, etc. The fireplace
area must be kept clear and free from combustible materials, gasoline and other flammable vapours and liquids.
• Under no circumstances should this fireplace be modified.
• This fireplace must not be connected to a chimney flue pipe serving a separate solid fuel burning appliance.
• Do not use this fireplace if any part has been under water. Immediately call a qualified service technician to inspect the fireplace
and to replace any part of the control system and any gas control which has been under water.
• Do not operate the fireplace with the glass door removed, cracked or broken. Replacement of the glass should be done by a
licensed or qualified service person.
• Do not strike or slam shut the fireplace glass door.
• This fireplace uses and requires a fast acting thermocouple. Replace only with a fast acting thermocouple supplied by Wolf
Steel Ltd.
• Pressure relief doors must be kept closed while the fireplace is operating to prevent exhaust fumes containing carbon monox-
ide, from entering into the home. Temperatures of the exhaust escaping through these openings can also cause the surrounding
combustible materials to overheat and catch fire.
• Only doors / optional fronts certified with the unit are to be installed on the appliance.
!
WARNING
