SPECIFICATIONS
10
POWER SPECIFICATIONS XA-900 XA-1100
2
Ω
400 + 400 730 + 730
4
Ω
300 + 300 475 + 475
8
Ω
200 + 200 300 + 300
Bridged 4
Ω
675 1100
ELECTRICAL SPECIFICATIONS XA-900 XA-1100
INPUT SENSITIVITY 1.15V (+3.4dBU) 1.15V (+4dBU)
INPUT IMPENDANCE 10K
Ω
Unbalanced & Balanced
FREQUENCY RESPONSE 20Hz~20KHz +/-1dB
(at 10dB below rated output power) -3dB points:5Hz~50KHz
VOLTAGE GAIN 32dB 34dB
DISTORTION (SMPTE-1M) <0.03% <0.03%
S/N RATIO 100dB 100dB
GENERAL SPECIFICATIONS XA-900 XA-1100
Full short circuit, open circuit, thermal,
PROTECTIONS ultrasonic, and RF protection; stable into
reactive or mismatched loads; ON/OFF
muting; current limiter (crowbar)
Front: Power switch, 40 dentent input level
control for each channel. Rear Parallel/
CONTROLS Mono/Bridge selector, ground lift switch,
AC voltage selector switch
SIGNAL 2x green LED
INDICATORS CLIP: 2 x red LED
POWER: 2 x green LED
PROTECT: 2 x red LED
CONNECTORS POWER: IEC power cord jack
INPUT: Active balanced XLR and
1/4” 6.3mm) TRS
OUTPUT: “Touch-proof” binding posts
POWER SUPPLY Voltage selectable: 110-120V or 220~240V
AC 50/60Hz
FUSES 3AG, 20A/250V (X2)
DIMENSIONS 19.0” x 15.7” x 3.5” (483 x 400 x 88.8mm)
WEIGHT 38.5lb (17.5Kg) 41.8lb (18.8Kg)
The specifications above are correct at the time of printing of this manual. For improvement purposes, all specifications
for this unit, including design and apperance, are subject to change without prior notice.
EIA OUT POWER
1HZ, THD MAXIMUM 1%
BOTH CHANNELS
