Architectural & Engineering Specifications
August 2001
Decorator-5
Ceiling Fans
MODEL: PFMB
DESCRIPTION
• Provides comfort and energy savings in two sizes. . .
simple elegant design converts to close-up.
• Includes five wood blades.
• Available in two sizes - 42" or 52" and in a choice of
four finishes: antique brass, polished brass, polished
brass with white blades or all white.
• Three speeds - high, medium and low - operated by
built-in pull chain.
• Dual mount hardware included (converts to close-up).
• Reversible operation.
• Detailed installation instructions included.
DESIGN FEATURES
Speed Range: 70-200 RPM.
Electrical Rating: 0.5 amps, 120 volts, 60 Hz.
Motor: Reversible three speed, PSC,
ball bearing.
Material: Blades:
• All White: white lacquer finish.
• Antique and Polished Brass: Teak
veneer with lacquer top coat.
Blade Brackets:
• All White: Zinc diecast with white
lacquer finish.
• Antique and Polished Brass:
Zinc diecast, plated finish with clear
lacquer top coat.
Miscellaneous: Blade Brackets balanced with
one (1) gram.
Blades balanced within two (2) grams.
Wire lead length: 56"
Blade Sweep: PFMB-42 Series: 42"
PFMB-52 Series: 52"
•••••••••••••••••••••••
42" Fan Housing Finish Blade Finish 52" Fan
PFMB-42AB Antique Brass Teak PFMB-52AB
PFMB-42BR Polished Brass Teak PFMB-52BR
PFMB-42WB Polished Brass w/White Blades White PFMB-52WB
PFMB-42WH All White White PFMB-52WH
ARCHITECT'S SPECIFICATIONS
NuTone PFMB Series Paddle Fans shall be manufactured
per listed specifications.
NUTONE, INC. / 4820 RED BANK ROAD, CINCINNATI, OHIO 45227
Product specifications subject to change without notice.
REFERENCE QTY. REMARKS Project
Location
Architect
Engineer
Contractor
Submitted by Date
