Cabinet Dimensions
ME NU
EN
TE R CA NC
EL
SELECT
POWER
STATUS
ON/OFF
SOURCE AUTO ADJUST
AC IN
USB
1.5 (0.06") 281 (11.06")
73.5 (2.89")
121 (4.76")
4
(0.16")
6.6 (0.26")
364 (14.33")
Lens center 39.5
(1.56")
Lens center
PC CONTROL
REMOTE CONTROL INPUT
MOUSE OUTPUT
S-VIDEO
VIDEO
AUDIO
RGB INPUT
AUDIO MONITOR OUTPUT
RGB OUTPUT
L / MONO
R
Unit = mm (inch)
MT840/MT1040
