Features of the BCM 104 and the BCM 705
• Characteristic, functionally optimized design*
• Integrated, neutral pop protection (1)
• Integrated elastic suspension (2)
• Individual headgrilles for diff erent users
• Colored rings to identify the replacement headgrilles
• Easy removal and cleaning of microphone headgrille (with bayonet mount) (3)
• Mechanical compatibility with standard studio boom arms
BCM 104
• Logo color: red
• Large-diaphragm condenser capsule (4)
• Cardioid directional characteristic
• Internal switches: high-pass and pre-attenuation
• Order number 08483
Technical data
Frequency range 20 Hz...20 kHz
1.7 mV/Pa = –55.4 dB ± 1 dB
Equivalent SPL, CCIR 468-3 32 dB
Equivalent SPL, DIN/IEC 651 18 dB-A
Weight 500 g
D x L x H (without suspension) 64 x 85 x 110 mm
BCM 705
• Logo color: green
• Dynamic capsule (5)
• Hypercardioid directional characteristic
• Multi-level isolation from structure-borne noise
• No power supply required
• Order number 08507
Technical data
Frequency range 20 Hz...20 kHz
Sensitivity 22 mV/Pa = –33.1 dB ± 1 dB
Equivalent SPL, CCIR 468-3 18 dB
Equivalent SPL, DIN/IEC 651 7 dB-A
Weight 500 g
D x L x H (without suspension) 64 x 85 x 110 mm
Selected accessories
• BCK headgrille, order number 08520 (6)
• SG 5 stand mount, order number 08529 (7+8)
• MF 3 table stand, order number 07321 (8)
The SG 5 stand mount allows the microphone to swivel
an additional +/-- 90°.
The Broadcast Line
5 4
3 1 2
7 8 6
