7
S P E C I F I C AT I O N S
The specifications above are correct at the time of printing of this manual. For improvement purposes, all specifications for this unit, including design
and appearance, are subject to change without prior notice.
Power Amp Section
..............................................................................................................................Tubes: 2 ea 6L6GC
Power Output
........................................................................................60 Watts @ 8
Ω
5% THD; 40 Watts @ 4
Ω
5% THD
Speaker
....................................................................................................Nady PowerDrive™ PD-12i by Celestion, 12” 8
Ω
Preamp Section
....................................................................................................................................Tubes: 3 ea 12AX7A
Input Imp.
.................................................................................................................................................................. 200K
Ω
Input Sens.
.................................................................................................. Max clean 800Mv 1KHz; Max dist. 8Mv. 1KHz
Line Out Inp.
................................................................................................................................................................ 600
Ω
Line Out Level
.................................................................................................................................................... 1V Nominal
Power Requirements
............................................................................................................ 115VAC/60Hz; 230VAC/50Hz
Fuse
............................................................................ For 115 VAC: 3 AMP S.B. 250V; For 230 VAC: 1.5 AMP S.B. 250V
Dimension
.......................................................................................................... 18.3” x 9” x 17.5” (46.5 x 22.9 x 44.5 cm)
Weight
...................................................................................................................................................... 45.6 lbs. (20.7 kg)
TUBE REPLACEMENT
Preamp Tubes 12AX7A
— No adjustment required
Output Tubes 6L6GC
— After replacing output tubes, output tubes bias voltage should be checked with Standby switch
set to On, no signal input, and all controls set to minimum. If output tube bias voltage is not correct, amplifier will sound
unusually distorted with mushy audio and output tubes may overheat. Normal output tube bias voltage should be —
52VDC on Pin 5 of all output tubes. For best results use matched output tubes.
