8
STEP 3 – Side Cap Assembly
a) Attach Side Cap with (3) M4 x 6mm Phillips
Screws at the bottom of the Upright.
Repeat on other side.
b) Use the Multi Hex Tool with Phillips
Screwdriver provided to tighten.
Figure 3 - Install Side Caps
upright
M4 x 6mm
phillips screws
side cap
Assembly is now complete.
IMPORTANT:
Follow the “Setting Up Treadmill For Use”
instructions on the next two pages to move
the Treadmill off the shipping carton so you
may begin your workout.
