5. OPERATION INSTRUCTIONS
The scope is mounted on a weapon by means of clamp, which
consists of bracket 16 (Fig.1, 2), lock screw 2, latch 13, lock
lever 14, handle 15 and washer 11.
Mount the scope on a weapon in the following order:
-
pull the handle 15;
- direct the scope from the rear side into aligning bar of a
weapon and push the scope forward to stop;
- push the handle 15 up to its catching;
- check up the reliability of scope fastening
A swinging of the scope on a weapon is not affordable.
For reliable fastening of the scope, it is necessary to adjust the
clamp in the following order:
-
detach the scope from the weapon;
- unlock the latch 13;
- shift the handle 15 providing the reliable fastening;
- lock the latch 13;
- check the reliability of scope fastening again.
For mounting and checking the serviceability of the scope
under daylight conditions do as follows:
-
put the cup with light filter on the lens;
