0 Chapter 6 Reference
Movable range Tilt
30° Up, 0° Down
Swivel
172° Right, 172° Left
Adjustable height 225 mm (8.9 inch) (174 mm (6.9 inch) when Tilt is 0°)
Rotation
90° (clockwise)
Environmental
Conditions Temperature
Operating temperature: 0 °C - 35 °C (32 °F - 95 °F)
Storage temperature: -20 °C - 60 °C (-4 °F - 140 °F)
Humidity Operating humidity: 20% - 80% R.H. (no condensation)
Storage humidity: 10% - 80% R.H. (no condensation)
Pressure
Operating: 700 to 1,060 hPa
Storage: 200 to 1,060 hPa
USB Standard
USB Specification Revision 2.0
Port Upstream port × 1, Downstream port × 2
Communication Speed 480 Mbps (high), 12 Mbps (full), 1.5 Mbps (low)
Supply current Downstream: Max. 500mA/1 port
CG243W
LCD Panel Size
24.1-inch (610 mm) TFT color LCD
Surface treatment
Hard Coating
Surface hardness
3H
Viewing angle
Viewing angle : Horizontal 178°, Vertical 178° (CR:10 or more)
Dot Pitch 0.270 mm
Response Time Approx. 13ms
Horizontal Scan
Frequency
Analog
24-76 kHz
Digital
26-78 kHz
Vertical Scan
Frequency Analog
47.5-86 Hz(1600 Ч 1200, 1920 Ч 1200: 49-61 Hz)
Digital
23.75-63 Hz (VGA TEXT: 69-71 Hz)
Frame
Synchronous
mode Analog
47.5-61 Hz
Digital
23.75-30.5 Hz, 47.5-61 Hz
Resolution 1920 dots × 1200 lines
Recommended Brightness 120 cd/m 2
or less (with color temperature of between 5000K to 6500K)
Max. Dot Clock Analog
170 MHz
Digital
164.5 MHz
Max. Display Color Approx. 1073.74 million colors (DisplayPort 10bit)
Display Area (H × V)
518.4 mm × 324.0 mm
Power Supply
100-120/200-240 VAC ±10%, 50/60Hz, 1.0A/0.5A
Power
Consumption Screen Display On 95W or less (with USB load)
85W or less (without USB load)
Power saving mode 0.9W or less (for DVI-I (Analog) single signal input, without USB load,
[Input Selection] : “Manual”)
Power button Off 0.7W or less (without USB load)
Main Power switch Off 0W
Input Signal Connector
DVI-I connector (Applicable to HDCP) × 2
DisplayPort (Standard V1.1a, applicable to HDCP)
