Pic. 2
1. Body
2. On/Off Switch
3. Battery House Cover
4. Mount Screw
5. Adjustable Angle Locking Ring
6. Lens Focusing Ring
7. USING THE NZT1-M2 WITH CAMERA
To use a camera with the NZT1-M2, use a camera with Pentax
Screw type thread. Adapters for most other cameras should be
available in your local camera store.
A camera adapter is supplied with your night vision scope.
See Pic. 3 for attachment instructions.
12
5. CONSTRUCTION
1. Body
2. Locking Screw
3. Lens
4. IR Illuminator
5. Lens
Focusing Ring
6. Tripod Socket
7. On/Off Switch
8. Battery
House Cover
9. Eye-piece
Focusing Ring
Pic. 1
1. Body
2. Locking Screw
3. Lens
4. IR Illuminator
5. Lens Focusing Ring
6. Tripod Socket
7. On/Off Switch for the Scope
8. Battery House Cover
9. Eye-piece Focusing Ring
9
1. Body
3. Battery
House Cover
2. On/off Switch 4. Mount Screw
5. Adjustable Angle
Locking Ring
6. Lens
Focusing Ring
