1996 Jan 08
9
Philips Semiconductors
Product specification
2
×
40 W/2
Ω
stereo BTL car radio
power amplifier with diagnostic facility
TDA8560Q
AC CHARACTERISTICS
V
P
= 14.4 V; R
L
= 4
Ω
; f = 1 kHz; T
amb
= 25
°
C; measured in Fig.6; unless otherwise specified.
SYMBOL
PARAMETER
CONDITIONS
MIN.
TYP.
MAX.
UNIT
P
o
output power
THD = 0.5%
16
19
−
W
THD = 10%
21
25
−
W
THD = 30%
28
35
−
W
P
o
output power
V
P
= 13.2 V
THD = 0.5%
−
15
−
W
THD = 10%
−
21
−
W
THD
total harmonic distortion
P
o
= 1 W
−
0.1
−
%
