Pump Exploded View
25
REF# PART# DESCRIPTION QTY MODEL
26
779828 Comet BXD 2530G Pump
1
1578112
1577544
789205 Cat 4DNX Pump 1578172
781209 NorthStar NSZW Pump 1578203
788598 Cat 3SPX Pump 1578182
781211 Comet AWD Pump 1578152
38520 Cat 66DX Pump 1578202
779827 Comet VRX 2528G Pump 1577543
781210 NorthStar NSLW Pump 1578173
27 777915 Quick Connect Outlet Plug 1 All
28
4027 Inlet Filter Washer
1
1578112, 8152, 8173,
8203, 7543
38596 3/8” Inlet Filter 1578172,8182
35169 1/2” Inlet Filter 1578202
29 777340
¼” x ¼” Hose Barb Fitting
1 1578172,8112, 8202, 8152
30 777834 ¼” Hose Clamp 2 1578172,8182, 8202, 8152
31 777165
¼” PVC Hose
12” 1578172,8182, 8202
10” 1578152
32
38584
Easy Start Valve
1 1578172,8182, 8202
CO06080032 1 1578152
33 777347 3/8” Street Tee 1 1578172,8182, 8202
34
35918
Thermal Valve 1
1578172,8182
777836 1578202
35 777376 Pop Off Valve 1 1578182, 8202
36 30483 Inlet Fitting 1 1578152
44 777410 3/8 Street elbow
3 1578182
1 1578202
