AUDIO
Controls the volume of the speakers or headphones.
To mute the speaker output, press the “1
2/RESET” button.
BRIGHTNESS
Adjusts the overall image and background screen brightness.
To enter the ECO MODE, press the “1
2/RESET” button.
ECO MODE OFF: Set brightness variable from 0% to 100%.
ECO MODE1:
AS191WM: Set brightness 80%.
AS221WM: Set brightness 70%.
This setting can adjust brightness within the range that power has reduced meeting Energy Star measurement
condition.
ECO MODE2:
AS191WM: Set brightness 30%.
AS221WM: Set brightness 20%.
This setting can adjust brightness within the range that power has reduced 30% from maximum brightness setting.
CONTRAST
Adjusts the image brightness in relation to the background.
AUTO CONTRAST
Adjusts the image displayed for non-standard video inputs.
AUTO ADJUST
Automatically adjusts the Image Position, the H. Size and Fine setting.
LEFT/RIGHT
Controls Horizontal Image Position within the display area of the LCD.
DOWN/UP
Controls Vertical Image Position within the display area of the LCD.
H. SIZE
Adjusts the horizontal size by increasing or decreasing this setting.
FINE
Improves focus, clarity and image stability by increasing or decreasing this setting.
COLOUR CONTROL SYSTEMS
Five colour presets (9300/7500/sRGB/USER/NATIVE) select the desired colour setting.
COLOUR RED
Increase or decreases Red. The change will appear on screen.
COLOUR GREEN
Increase or decreases Green. The change will appear on screen.
COLOUR BLUE
Increase or decreases Blue. The change will appear on screen.
TOOL
Selecting TOOL allows you to get into the sub menu.
FACTORY PRESET
Selecting Factory Preset allows you to reset all OSD control settings back to the factory settings. The RESET button
will need to be held down for several seconds to take effect. Individual settings can be reset by highlighting the
control to be reset and pressing the RESET button.
