5. OPERATION INSTRUCTIONS
1 – Low battery indicator
2 – Reticle (either
-¦-
or )
3 – Units of measurement
4 – Measurement result
5 – Target quality indicator 6 – Laser active indicator
7 – Setup mode indicator
8 – Ready mode indicator
4
6
2
1
3
8
7
Fig. 3. Liquid Crystal Display as
seen through the eyepiece
5
