Niles Audio C5-RFWM User Manual

C5-rfwm

I N S T A L L A T I O N G U I D E

C5-RFWM

F O R P L A C I N G C A T V D E V I C E S E X T E N D E D
D I S T A N C E S F R O M T H E I R A / V S O U R C E

C A T - 5 C A B L E T V W A L L M O U N T B A L U N

CONGRATULA

TIONS!

Thank you for choosing the

C5-RFWM Cable TV Balun from Niles.

With proper installa

tion

and operation,

you’ll enjoy years of trouble free use.

Niles manufacturers the industry’

s most complete line of custom installation components and

accessories for audio/video systems. To see the complete assortment,

visit our website at

www.nilesaudio.com.

INTRODUCTION

The C5-RFWM is a stand-alone device that transforms a CA

TV signal to and from CAT-5

twisted pair cabling. It has two sets of simple connections.

The ﬁrst is a female F connector

for the line RF CATV signal.

The second is a shielded CA

T-5 connector for the CA

T-5 twisted

pair connection. The circuitr

y is passive so there is no need for a power supply

In today’s retroﬁt market an installer cannot al

ways successfully run a wire from point A to

point B. There exists ho

wever an abundance of twisted pair cabling in many homes.

By using

a pair of these devices with an existing wire an installer may be able to complete a job that he

otherwise could not.

FEATURES

• Shielded CAT-5 Connector

• Ten-y

ear limited warr

anty

SPECIFICATIONS

• Overall dimensions:

1.75" (44.5 mm) W x 2.84" (7.2 mm) H x 1.99" (5 mm) D

• Cut out size: 1.87" (47.5 mm)

W x 3.00" (76.2 mm) H x 2.50" (63.50 mm) D

• Bandwidth: 5 MHz to 550 MHz

• Tr

ansmission Distance: Up to 330' (100 m) using CA

T-5 UTP

N i l e s A u d i o C o r p o r a t i o n

1 2 3 3 1 S . W . 1 3 0 S t r e e t M i a m i , F l o r i d a 3 3 1 8 6

3 0 5 - 2 3 8 - 4 3 7 3

1 - 8 0 0 - B U Y - H I F I w w w . n i l e s a u d i o . c o m

Blending High Fidelity and Architecture are registered trademarks of Niles Audio Corporation.

All other trademarks are the property of their respective owners. D S 0 0 5 7 3 B

L E N D I N G

I G H

I D E L I T Y

N D

R C H I T E C T U R E

• 1-Gang Decora Style

• Decora w

all plate included
