Page 10
10
W415-0360 / 11.05.02
MODEL 1401/1400L - FIGURE 20
MODEL 1101/1100L - FIGURE 18
12
12
10
10
10
10
11
11
11
11
MODEL 1400 - FIGURE 19
MODEL 1100/1100C - FIGURE 17
BRICK RETAINER DETAIL - TYPICAL
MODEL 1900 - FIGURE 21
AREA CIRCLED ON EACH FIGURE INDICATES
THE BRICK RETAINER DETAIL
SIZES
#1. 1-1/4" x 4"-1/2 x 9"
#2. 1-1/4" x 3" x 9"
#3. 1-1/4" x 4-1/2" x 4-1/2"
#4. 1-1/4" x 4-1/2" x 9"
#5. 1-1/4" x 2-1/2" x 4-1/2"
#6. 1-1/4" x 1-1/2" x 4-1/2"
#7. 1-1/4" x 4-1/2" x 9"
*
(light weight)
#8. 1-1/4" x 2-1/4" x 9"
#9. 1-1/4" x 2-1/4" x 6-1/8"
#10. Fibre baffle - 9” x 1” x 12”
#11. Fibre baffle - 9” x 1” x 16 1/2”
#12. Fibre baffle - 9” x 1” x 19 1/2”
BACK
SIDES
TOP
FLOOR
FRONT
1100/1100C
1101/1100L
1400
1401/1400L
1900
4-#1
4-#1
4-#1
4-#1
4-#7*
2-#4
2-#4
2-#4
2-#4
2-#2
8-#1
8-#1
12-#1
12-#1
12-#7*
2-#3
2-#3
2-#3
2-#4
(notched)
2-#102-#10
2-#11
2-#11
2-#12
3-#1
4-#1
5-#1
6-#1
7-#7*
2-#2
2-#2
2-#2
2-#2
2-#2
1-#5
1-#5
1-#5
1-#6
1-#6
1-#6
2-#2
2-#2
2-#2
2-#2
2-#2
1-#8
1-#8
1-#8
1-#8
1-#8
1-#9
1-#9
1-#9
1-#9
1-#9
FINISHING
