Rev. 041008 6
Functional Overview
The 105TX-POE and 105FX-POE Power over Ethernet Unmanaged Industrial Ethernet Switches are
designed to provide power over Ethernet for POE capable devices where running a power line is either not
possible or not cost effective. This feature allows an end user to power a POE camera, wireless access
point, or any other POE capable device without the need for running separate wires for power. This also
allows the ability for a centralized battery backup for all these devices.
The 105FX-POE utilizes the IEEE compliant SC or ST duplex connectors for fiber optic communication.
All 10/100Base-TX ports utilize the RJ45 shielded connectors.
Key Features
•
Compact, space saving package
•
Full IEEE 802.3 & 100Base-FX Compliance
•
IEEE 802.3af Compliant
•
105TX-POE - Five 10/100Base-TX RJ-45 ports (4 PSE ports and 1 uplink port)
•
105FX-POE - Four 10/100Base-TX RJ-45 ports (4 PSE ports and 1 100BaseFX fiber uplink port)
•
Unmanaged operation
•
Extended Environmental Specifications
-40°C to 85°C Operating Temperature
-40°C to 85°C Storage Temperature
•
Operating Humidity: 10% to 90% (Non Condensing)
•
Support for Full/Half Duplex Operation
•
LED Link/Activity Status Indication
•
LED POE Status Indication
•
Power Fault Status LEDs
•
Auto-negotiation, Auto-sensing Speed, Duplex, and Flow Control
•
Up to 1.0 Gb/s Maximum Throughput
•
Industry Standard 35mm DIN Rail Mounted Enclosure
•
Redundant power inputs (46-49 VDC)
•
Supports up to 15.4Watts per channel (13 Watts at the Powered Device (PD ))
•
Full wire speed communications
•
Hardened metal DIN Rail Enclosure
