RFT2 Rack Kit Installation Guide
07/01/06 Rev 1.0 Page 12 of 13
Specifications
General Compatibility
Keyboard Type 6 and Type 7
USB Ports USB 1.1 and 2.0
Rack 4 Post EIA
Systems Solaris – SPARC
LCD Panel Specifications
LCD Native (Pixel) Resolution 1280x1024
Protective Covering 2mm strengthened glass
Keyboard Specifications
Type USB 1.1
Pointing Device Three button integrated trackball
General Specifications
Form Factor 1U rack mounting on slide-out rails
Size (without Rackslides) 1.75 x 19.0 x 26.3in (45x483x668mm HxWxD) (without ears)
Length (with Slides and Cable Mgt) 31 inches
Weight (unpackaged) 32 lbs (15.4 Kg)
Storage/Operating Temperature Range -25°C to +60°C / 0°C to +50°C
Operating Humidity 5 to 95% RH (non-condensing)
Approvals EMC: EN55022 Class A, FCCA, RoHS, Solaris Ready Certified,
Safety: CSA 22.2.950, NRTL/C, IEC 950, EN60950, CE Approval
Power Supply Internal auto-ranging 90-264VAC 50/60Hz
Power Consumption 25W (<5W in standby)
Warranty 24 months
