CONNECTION BETWEEN PLAYE RS
AVP CABLE
Connect the two players with AVP cable as described below:
1. First, connect the AVP cable and the main unit by inserting the DC OUT
section of the cable to the DC OUT socket of the main unit.
2. Second, plug the DC IN section of the cable to the DC IN socket of the monitor.
Monitor
Main unit
ENG
MOBILE ENTERTAINMENT
23
DC IN (Black)
Video(Yellow)
Audio(White)
(Bl ck) DC OUT
a
(
) Video
Yellow
(
) Audio
White
