W415-0326 / C / 11.23.07
18
MINIMUM MANTEL AND ENCLOSURE
CLEARANCES
Combustible mantel clearance can vary according to the mantel
depth. Use the graph to help evaluate the clearance needed. Cur-
tains, above the fi replace, must not be positioned lower than the
2" distance required for the 2" combustible mantel. These same
requirements apply to any combustibles protruding on either
side of the fireplace.
The fi replace
requires a minimum
enclosure height of 55“.
For temperature requirements,
the enclosure space around and
above the fi replace must be left unobstructed.
FIGURE 36
FIGURE 38b
FIGURE 38a
FIGURE 38c
FIGURES 35a-b
FIGURES 37
* See venting section
