Styleline series molded bath cabinets, Specification sheet
SPECIFICATION SHEET
Broan-NuTone Storage Solutions, 501 S. Wilhite Street, Cleburne, TX 76031 (1-800-325-8351)
REFERENCE
QTY.
REMARKS
Project
Location
Architect
Engineer
Contractor
Submitted by Date
SURFACE
MOUNT
RECESSED
A
B
C
D
E
F
MODEL
OVERALL SIZE
WALL OPENING
NO.
A B C
D E F SHELVES
401ADJ
16 20 3
3
/
4
14 18 2
1
/
2
2 (adj)
407ADJ
16 22 3
3
/
4
14 18 2
1
/
2
2 (adj)
624
16 26 4
1
/
2
13
7
/
8
23
7
/
8
2
7
/
8
3 (fi xed)
RECESSED CABINETS
STYLELINE SERIES
MOLDED BATH
CABINETS
Standard builder models - for recessed and
surface mount installation
FEATURES
•
Easy to clean, one-piece, injection-molded
polystyrene
construction
•
Glass Mirror
•
Stainless steel frame
•
Butt hinge
•
Polystyrene shelves (fixed or adjustable)
•
Reversible - for left-hand or right-hand
door
opening
•
Includes mounting hardware
80D A99044182 B
SURFACE MOUNT CABINET
TYPICAL SPECIFICATION
Bath cabinet shall be NuTone Styleline Series Model
401ADJ, (407ADJ), (614) and (624).
Bath cabinet shall be of one-piece, injection-molded
polystyrene construction.
Glass mirror shall have full surround of stainless steel
frame with spring clip closure (401ADJ & 407ADJ) or
screw closure (614 & 624). Door back shall be fitted
tight within the frame and finished in white.
Cabinet shall have butt hinges.
Cabinet shall be reversible for left-hand or right-hand
installation.
MODEL
BODY SIZE
OVERALL SIZE
NO. A B
C
D E
F SHELVES
614
15
5
/
8
19
5
/
8
3
5
/
8
16
1
/
4
22
1
/
4
4
1
/
4
2 (fi xed)
E
D
B
C
F
A
