3
W415-0257 / 08.02.01
TABLE of CONTENTS
PG 2-4 INTRODUCTION
Warranty
General Information
Principals of Operation
Care of Glass
4-6 INSTALLATION
Stove Installation
Flue collar assembly
Chimney Connection
Adding Chimney Sections
Ash Fender Installation
Andiron Installation
Optional Fan Instructions
Adjusting Door Closing Pressure
PG 7-8 OPERATING INSTRUCTIONS
Achieving Proper Draft
Fire Extinguishers and Smoke Detectors
Fuel Loading and Burn Cycle
Flash Fire
Extended Fire
Ash Removal Procedures
9 WOOD PILE MAINTENANCE
9 STOVE MAINTENANCE
Creosote Formation and Removal
Runaway or Chimney Fire Smoking
Gasket Replacement
10-11 REPLACEMENTS
Ordering Replacement Parts
Replacement Parts
PLEASE RETAIN THIS MANUAL FOR FUTURE REFERENCE
*FIGURES WILL VARY CONSIDERABLY WITH INDIVIDUAL CONDITIONS.
** WOLF STEEL LTD. ESTIMATED REALISTIC BTU/H WITH HARDWOOD LOGS AND REGULAR REFUELING.
WIDTH X DEPTH 21 1/16" X 15 1/2" (535 x 393 mm)
HEIGHT 27 1/2" (700 mm)
CHAMBER (W.D.H.) 17 x 9 1/2 x 14 3/8" (450 x 240 x 365 mm)
APP. AREA HEATED* 600 - 1200 ft 2 (56 - 112 m 2 )
HEAT OUTPUT (HIGH BURN)** 40,000 BTU
WEIGHT 220 lb (100 kg)
SPECIFICATIONS
NOTE: CHANGES, OTHER THAN EDITORIAL, ARE DENOTED BY A VERTICAL LINE IN THE MARGIN.
27 1/2"
700mm
21 1/16"
535mm
16"
406mm
15 1/2"
393mm
