Below is an example of N-Ring Status from an N-Ring Manager with a healthy N-Ring:
N-Ring OK
N-Ring Status View
Switch is an N-Ring Manager, using N-Ring Aging Time = 20 Seconds
Refresh every
6
secs.
Update Pause Print...
12 Active Members Detected In Current N-Ring (12 reporting)
Switch No MAC Address IP Address Subnet Mask Name Ports
RM 00:07:af:ff:e4:a0 192.168.1.227 255.255.255.0 N-TRON Switch
A2
A1
1 00:07:af:ff:ef:60 192.168.1.224 255.255.255.0 N-TRON Switch
A2
A1
2 00:07:af:ff:e6:a0 192.168.1.217 255.255.255.0 N-TRON Switch
A2
A1
3 00:07:af:ff:ef:80 192.168.1.221 255.255.255.0 N-TRON Switch
A2
A1
4 00:07:af:ff:e4:c0 192.168.1.241 255.255.255.0 N-TRON Switch
A2
A1
5 00:07:af:ff:d5:e0 192.168.1.229 255.255.255.0 N-TRON Switch
A2
A1
6 00:07:af:ff:d7:00 192.168.1.228 255.255.255.0 N-TRON Switch
A2
A1
7 00:07:af:ff:e6:c0 192.168.1.223 255.255.255.0 N-TRON Switch
A2
A1
8 00:07:af:ff:d5:20 192.168.1.231 255.255.255.0 N-TRON Switch
A2
A1
9 00:07:af:ff:e5:e0 192.168.1.238 255.255.255.0 N-TRON Switch
A2
A1
10 00:07:af:ff:e3:c0 192.168.1.239 255.255.255.0 N-TRON Switch
A2
A1
11 00:07:af:ff:d5:40 192.168.1.230 255.255.255.0 N-TRON Switch
A2
A1
12 00:07:af:ff:e3:e0 192.168.1.215 255.255.255.0 N-TRON Switch
A2
A1
