Page 24

English-22

SCHEDULE RESET

Resets the following settings within the SCHEDULE menu back to factory setting:

OFF TIMER, SCHEDULE SETTINGS.

KEEP PIP MODE

Allows the monitor to remain in “PIP” and “TEXT TICKER” mode after powering off.

OFF

When Power is returned, PIP and TEXT TICKER appear without having to enter the OSD.

PIP MODE

Picture-in-Picture

OFF

PIP

POP

SIDE BY SIDE (ASPECT) SIDE BY SIDE ASPECT

SIDE BY SIDE (FULL)

SIDE BY SIDE FULL

PIP SIZE

Selects the size of the sub-picture used in Picture-in-Picture (PIP) mode.

LARGE

SMALL

MIDDLE

LARGE

PIP POSITION

Determines where the PIP appears on the screen.

X = 95, Y = 92

ASPECT

Selects sub picture aspect, [FULL], [NORMAL], [WIDE] and [ZOOM]. See page 17.

FULL

TEXT TICKER

Allow text insertion within main screen with the ability to adjust for direction, position, size,

OFF

blend for transparency rate, detect and fade in. The TEXT TICKER and PIP functions cannot be
used simultaneouslly. If the PIP function is on, it will be deactivated and vice versa if the
TEXT TICKER is turned on.

SUB INPUT

Selects sub picture input signal.

Depend on signal input

PIP RESET

Resets PIP options back to factory settings except ASPECT and SUB INPUT.

LANGUAGE

Select the language used by the OSD.

ENGLISH

DEUTSCH

FRANÇAIS

ITALIANO

ESPAÑOL

SVENSKA

РУССКИЙ

OSD TURN OFF

Turns off the OSD after a period of inactivity. The preset choices are 10-240 seconds.

30 Sec.

OSD POSITION

Determines the location where the OSD appears on the screen.

X = 128, Y = 225

DOWN

LEFT

RIGHT

INFORMATION OSD

Selects whether the information OSD is displayed or not. The information OSD will be

ON, 3 Sec.

displayed when the input signal or source changes. The information OSD will also give a
warning when there is no-signal or the signal is out-of range.
An interval between 3 to 10 seconds for the Information OSD to appear is available.

MONITOR INFORMATION Monitor Information.

CARBON SAVINGS: Display the estimated carbon saving information in kg. The carbon
footprint factor in the carbon saving calculation is based on the OECD (2008 Edition).

PIP

OSD

(Depend on
destination)
