Thank you for your purchase of the NHT iW4 in-wall loudspeaker. Please take a few minutes to read through this Owner's
Manual prior to installing your new speakers. The information provided will help you to obtain maximum performance from
your audio system. If you have questions or need assistance at any time during the installation or operation of your new
speakers, please call your NHT Dealer or our Toll-Free Customer Hotline at:
1-800-NHT-9993
„ „ Design
NHT loudspeakers are designed to deliver refined, musical sound from attractive and affordable packages. Our efforts are
guided by the study of human hearing and are optimized for real-world use. Every NHT speaker undergoes rigorous
testing and quality control at the factory to ensure you years of listening pleasure.
The NHT iW4's custom-designed drive units are mounted in a rigid baffle/bezel assembly designed to minimize the
audible effects of unwanted vibrations and resonance. The baffle is 18mm MDF, the same material used in high quality
box speakers. It is separated from the bezel by absorptive materials designed to prevent the coloration of critical midrange
frequencies caused by wall vibration. The mounting assembly is designed to be intuitive and flexible, making it ideal for
new or existing construction. With high performance sonics and a paintable grille and frame, the iW4 is the perfect
solution for architectural audio and home theater installations.
Caution: The iW4 should be installed by an experienced and licensed custom installation professional. Be sure that the
installer possesses sufficient skill, the proper tools, knowledge of local fire and building codes, and a familiarity with the
structure of the building (especially wall and/or ceiling materials, layouts, electrical and plumbing lines, etc.).
iW4 Specifications
· System Type: 3-way in-wall design
· Driver Complement: (2) 5.25" long-throw polypropylene woofers, 2” aluminum dome midrange, 3/4" aluminum dome tweeter
· Crossover: 750Hz, 18dB/octave and 5KHz 18dB/octave
· Response: 50Hz - 20KHz, +/-3dB
· Sensitivity: 86dB (2.83V at 1M)
· Impedance: 8 ohms, min. 5.5 ohms.
· Recommended Amplifier Power: 20w/ch. min., 150w/ch. max.
· Inputs: Professional grade spring posts
· Weight: 10 lbs. each
· Dimensions: Cutout 13.56" x 9"; Bezel 14.7" x 10.1"; from front of wall to back of speaker: 3.19”
· Finish: Matte white (paintable)
Specifications are subject to change without notice, in accordance with our policy of continuously upgrading the performance of our products.
