North Star M1108D - Manual (Page 32)

Parts Breakdown – Exploded View 1108, 1109, 1114 – Rev D
32
Item Part No. Description Qty. Model Item Part no. Description Qty. Model
1 82140 1/8” x 2” COTTER PIN 4 ALL 3005 ¾” COUPLING 1 1108, 1109
2 124A DUST CAP 2 ALL
31
3007 1” COUPLING 1 1114
3 777124 AXLE NUT 2 ALL 32 3009 COUPLING INSERT 1 ALL
4 777799 WHEEL 2 ALL 3030 PUMP MOUNT BRACKET 1 1108, 1109
5 778844 WHEEL WASHER 2 ALL
33
778786 PUMP MOUNT BRACKET 1 1114
6 778387 AXLE/TANK 1 ALL 34 3002 ½” COUPLING 1 ALL
7 778424 DIPSTICK 1 ALL 1012 11 GPM 2-STAGE PUMP 1 1108, 1109
8 778498 CATCH PIN 3 ALL
35
1056 16 GPM 2-STAGE PUMP 1 1114
9 778876 OUTRIGGER LEG 2 ALL 37 778592 CYLINDER ANCHOR PIN 1 ALL
10 778403 TOWBAR 1 ALL 38 778827 O-RING BOSS X NPT ELBOW 4 ALL
11 778440 TIP-UP PIVOT 1 ALL 39 778642 O-RING BOSS X HB ELBOW 1 ALL
12 778578 VERTICAL BEAM LOCK 1 ALL 778616 ¾” SUCTION HOSE 18” 1108, 1109
13 778619 ½” NPT HP HOSE 1 ALL
40
778634 1” SUCTION HOSE 20.5” 1114
14 778619 ½” NPT HP HOSE 1 ALL 41 778885 HANDLE 1 ALL
15 778615 46” RETURN LINE 1 ALL 42 778343 HORIZONTAL BEAM LOCK 1 ALL
778435 CONTROL VALVE 1 1108 43 1130 SAFETY CHAIN 2 ALL
778624 CONTROL VALVE 1 1109 44 38587 2” COUPLER 1 ALL 16
778435 CONTROL VALVE 1 1114 17141 ½” HOSE CLAMP 2 1108, 1109
17 34025 HAND GRIP 2 ALL
45
777835 13/16” – 1 ¾” HOSE CLAMP 2 1114
18 779174 LOG CRADLE SUPPORT 4 ALL 5267 ¾” MPT X ¾” HB 1 1108, 1109
19 778431 LOG CRADLE FACE PLATE 2 ALL
46
38050 ¾” MPT X 1” HB 1 1114
20 778325 BEAM 1 ALL 47 4011 4” SUCTION STRAINER 1 1114
21 778873 8mm GREASE ZERK 4 ALL 48 778829 ¾” NPT X ¾” HB ELBOW 1 ALL
22 82115 7/16-14 NYLON NUT 17 ALL 49 777835 13/16” – 1 ¾” HOSE CLAMP 2 ALL
23 778380 WEDGE KEEPER, LEFT 1 ALL 50 4020 20 GPM FILTER 1 ALL
24 82258 7/16-14 X 2 ¼” SHCS 1 ALL 51 82065 #10-24 NYLON NUT 1 1109, 1114
25 82114 7/16-14 X 2” HHCS GRd 8 16 ALL 52 31094 #14S BRASS WASHER 2 1109, 1114
26 778321 WEDGE 1 ALL 53 778808 IDLE CONTROL BASE 1 1109, 1114
27 778723 WEDGE KEEPER, RIGHT 1 ALL 54 31095 ¼ NYLON WASHER 1 1109, 1114
778363 4 X 24” CYLINDER 1 1108 55 37991 EXTENSION SPRING 1 1109, 1114
778341 4.5 X 24” CYLINDER 1 1109 56 778470 IDLE CONTROL ARM 1 1109, 1114 28
778362 5 X 24” CYLINDER 1 1114 57 82058 ¼” X ¼” SHOULDER BOLT 1 1109, 1114
778736 LOG STRIPPER 1 1108 58 778831 O-RING X SWIV. FEM. NPT 1 ALL
778735 LOG STRIPPER 1 1109 59 778618 ½” MALE NPT HP HOSE 1 ALL 29
778734 LOG STRIPPER 1 1114 60 50RAS8 ½” M X ½” F SWIVEL NPT 1 ALL
60599 HONDA GC160, 5.0 HP 1 1108 61 778709 MUFFLER DEFLECTOR 1 1108
60590 HONDA GX160, 5.5 HP 1 1109 62 38477 IDLE CONTROL CABLE 1 1109, 1114 30
39115 HONDA GX270, 9.0 HP 1 1114 778513 22 Ton Decal 2 1108
778512 30 Ton Decal 2 1109 63
778511 37 Ton Decal 2 1114
64 STNS4 Northstar Decal 2 ALL
