DM1200/DM1235/DM1285
SPECIFICATIONS...
I N P U T S :
Line:10k
Ω
input impedance
80 mV rms sensitivity (for 1.22 V output)
Mic: 10k
Ω
input impedance balanced/unbalanced
2.5 mV rms sensitivity (for 1.22 V output)
500 mV rms max input
Phono: 47k
Ω
input impedance
1.5 mV rms sensitivity @ 1 KHz (for 1.22 V output)
O U T P U T S :
Line: 9V rms max (+20 dBm)
470
Ω
balanced. 3.5Vrms
100
Ω
balanced 1.12Vrms
Headphone Amp: .5 watt into 47
Ω
Distortion less than .01%
E Q U A L I Z E R :
6-Band Stereo Graphic EQ
Band centers 42 Hz, 152 Hz, 480Hz, 1.52KHz, 4.8KHz,
15.36KHz +/- 15 dB
SIGNAL TO NOISE RATIOS (vs. maximum
output):
Line:
Better than 85 dB
Mic: Better than 72 dB
Phono: Better than 83 dB
F R E Q U E N C Y R E S P O N S E :
Mic: 20 Hz- 15k Hz + _ .5 dB
Line: 20 Hz- 20k Hz + _ .5 dB
Phono: + _ 1 dB except for controlled attenuation
of -3 dB
@ 20 Hz to Reduce rumble and feedback
TALKOVER ATTENUATION:
variable from no cut to -16 dB
P O W E R C O N S U M P T I O N :
20 Watt typical, 28 watt with full headphone output
D I M E N S I O N S : 482mmx232mmx111mm
19” x9 1/8” x4 3/8”
WEIGHT: DM1200 4.3kgs 9.6lbs
DM1235/DM1285 5.1kgs 11.2lbs
D M 1 2 3 5 w i t h B E A T K E E P E R
Sync Lock Mode
BPM update rate
Every beat
BPM accuracy +/- 1 BPM
BPM tracking range 50-199BPM
Bar graph update rate Every beat
Tempo difference graph resolution
+/-1 BPM per LED, Green is +/-2 BPM
Beat offset graph resolution
+/-7.5msec per LED, Green is +/-15msec
Beat Assist Button
Minimum time between consecutive taps
0.3 seconds
Maximum time between consecutive taps
1.2 seconds
Consecutive taps averaging for BPM
Last 2 to 8 taps
DM1285 with SAMPLER:
FREQUENCY RESPONSE AND SAMPLING RATE:
Variable sampling rate 44.1 kHz with 16-bit sampling
yields 20Hz-22 kHz.
MAXIMUM MEMORY TIME:
12 seconds
