Neumann.Berlin KM D AES 42 - Manual (Page 4)

4
Popscreen PS 15
The frame is 15 cm in diameter.
PS 15 .................... blk ........ Cat. No. 008472
Popscreens
Pop screens provide excellent suppression of so-called pop noise,
such as “p” or “t”. They consist of a round, thin frame covered with
black gauze on both sides. A gooseneck of about 30 cm (12") in length is mounted at the popshield. It will be attached to micro-
phone stands by means of a clamp with a knurled screw.
Stand Mounts and Miscellaneous Mechanical Adapters
Stand Mount SGE 100
Swivel mount for detached miniature mi-
crophone capsules. A rubber shock
mount suppresses structure-borne
noise. The swivel mount has an M 6
thread (6 mm). Attaching the swivel
mount to the MF 2 table stand, the
SGE 100 replaces the rubber shock
mount of the table stand.
SGE 100 ............... blk ........ Cat. No. 006742
Stand Mount SG 109
Swivel mount for detached miniature mi-
crophone capsules. It has a 3/8" thread.
SG 109 ................. blk ........ Cat. No. 008614
Swivel Joint SG 110 nx
The SG 110 nx swivel mount can be in-
serted between KK 1... capsules and the
KM D output stage. The capsule can then
be swiveled and orientated through
± 110°. In combination with an elastic
suspension and a table flange, a mechan-
ically decoupled, unobtrusive setup can
be realised, e.g. for TV news announcers.
Length 60 mm, Ø 22 mm.
SG 110 nx ............ nx ......... Cat. No. 008611
Stereo Mount STH 100
Stereo mount with a swivel mount and
two holders, for two detached miniature
microphone capsules. Two stereo re-
cording methods are then possible.
One holder enables the microphone set-
up according to the “ORTF Method”:
Two detached capsules are snapped into
the clamps at the end of the holder. The
distance between diaphragms is then
170 mm, with an angle of 110°.
The other pair of holders allows stereo
setups according to the “Coincidence
Method”: Capsules are installed acousti-
cally at one point in space, however,
freely adjustable to any angle between
30° and 180°.
The swivel mount has a 5/8"-27 thread,
plus a thread adapter to connect to
1/2"- and 3/8" stands.
STH 100 ............... blk ........ Cat. No. 007315
Stereo Mount STH 120
The STH 120 stereo mount accepts two
detached miniature microphone cap-
sules, parallel and one above the other
for MS stereo recordings. It is rotatable
and swivelable. The swivel mount has a
5/8"-27 thread, plus a thread adapter to
connect to 1/2"- and 3/8" stands.
STH 120 ............... blk ........ Cat. No. 008422
