Nuvo E6G - Manual (Page 11)

Power Requirements
AC Power Input 90-264V/ 50/60 Hz
Power Consumption, operating 10W Max.
Power Consumption, standby 3W Max.
Memory Backup Indefinite
Infrared Specifications
Input Voltage 3-15 V
Input Carrier Frequency 38 kHz nominal
Polarity Active High
Physical Specifications
Unit Size 1.75”W x 17”D x 10.625”H (44 x 430 x 270 mm)
Shipping Size 8.07” H x 20.3” W x 13.5” D (205 x 515 x 343 mm)
Unit Weight 7.5 lbs. (3.4 kg)
Shipping Weight 14.3 lbs. (6.5 kg)
Audio Specifications
Outputs 2 Stereo
Output level Adjustable
Output Impedance 560 ohms
AM Specifications
Tuning Range 522 to 1720 kHz
IF Frequency 450 kHz
Usable Sensitivity 25 dB S/N
Auto Scan Sensitivity Adjustable
Image Rejection 50 dB Min.
FM Specifications
Tuning Range 87.5 to 108 MHz
IF Frequency 10.7 MHz
Usable Sensitivity, 30 dB S/N 14 dB µV
Auto Scan Sensitivity Adjustable
Image Rejection 50 dB Min.
Limiting Sensitivity 10 dB µV
XM ® Specifications
XM ® Band 2332.5 to 2345 MHz
NuVoDock for iPod® Specifications:
Wireless NuVoDock
RF Frequency Range 2400-2483.5 MHz
Number of RF Channels 3
Output Power 16 dBm typ
Range 150 ft. typ*
RF Technology Proprietary
Frequency Response (20Hz - 20kHz) +/- 0.5 dB
THD (20Hz - 20kHz) .015%
Signal to Noise >87 dB
Power Supply 12V/5W DC 100-240 VAC
Network NuVoNet
NV-WIPD Dimensions 3.25”W x 2.5”D x 2.25”H (81.3 x 63.5 x 57.2 mm)
NV-WIPD Weight .35 lbs (0.16 kg)
NV-WIPR Dimensions 4.5625”W x .9063”D x 4.75”H (116.5 x 23.2 x 120 mm)
NV-WIPR Weight .25 lbs (0.11 kg)
Shipping Dimensions 4.65” H x 9.6” W x 8.35” D (118 x 244 x 212 mm)
Shipping Weight 2.4 lbs (1.1 kg)
*Maximum wireless signal range may vary. Network conditions and environmental factors, including building
materials and construction, may affect signal range.
Remote NuVoDock
Frequency Response (20Hz - 20kHz) +/-0.5 dB 0.25 dB @ 300 ft. CAT5
THD (20Hz - 20kHz) .015%
Signal to Noise 87 dB @ 300 ft. CAT5
Power Supply 12V/5W DC 100-240VAC
Network NuVoNet
NV-RIPD Dimensions 3.2” W x 2.5” D x 2.25” H (81.3 X 63.5 X 57.2 mm)
NV-RIPD Weight .4 lbs (.18 kg)
NV-RIPR-DC Dimensions 1.8125” W x 1.625” D x 4.625” H (45.7 x 33 x 118.1 mm)
NV-RIPR-DC Weight .15 lbs (.068 kg)
NV-RJ45P-DC Dimensions 1.8125” W x 1.625 ” D x 4.625 ” H (45.7 x 33 x 118.1 mm)
NV-RJ45P-DC Weight .15 lbs (.068 kg)
Shipping Dimensions 4.65” H x 9.6” W x 8.35” D (118 x 244 x 212 mm)
Shipping Weight 2.4 lbs (1.1 kg)
General Specifications
Supported iPod ® Models: iPod ® (4th generation & newer),
iPod ® mini (all versions), and iPod ® nano (all versions)
T2 Specifications (T2DFG, T2FXG, T2DXG):
Power Requirements
AC Power Input 90-264 VAC 50/60Hz
Power Consumption, operating 3 W max.
Power Consumption, standby 1 W max.
Memory Backup Indefinite
Infrared Specifications
Input Voltage 3–15 V
Input Carrier Frequency 38 kHz nominal
Polarity Active High
Physical Specifications
Unit Size 1.75” H x 17” W x 9.875” D (44 x 430 x 250 mm)
Shipping Size 8.07” H x 20.3” W x 13.5” D (205 x 515 x 343 mm)
Unit Weight 5.20 lbs. (2.36 kg)
Shipping Weight 14.3 lbs. (6.5 kg)
Audio Specifications
Outputs 2 Stereo Outputs
Level 1 Vrms
Impedance 470 ohms
SIRIUS Specifications
Requires a SIRIUS signal distribution kit, which can be purchased at most major
consumer electronics stores.
Satellite 2322.293/2330.207 MHz
Terrestrial 2326.250 MHz
FM
Tuning Range 87.5 to 108.0 MHz
De-emphasis 50/75 µs
Antenna Input 75 Ω (unbalanced)
AM
Tuning Range 520 to 1710 kHz
Antenna Input 75Ω (unbalanced)
Regulatory Approvals
Intertek Listed (cETLus)
USA Safety Listing (UL 60065)
FCC
Canada Safety Listing (CAN/CSA – C22.2 60065.06)
ENERGY STAR ®
T2 Specifications (T2SIR):
