21
W415-0098 / A / 08.07.03
GD175 WALL TERMINAL KIT
44 BM6790 90° ELBOW - 7" DIAMETER
45 GD222 TERMINAL ASSEMBLY
46 BM67ADJ 30" TO 53" ADJUSTABLE PIPE - 7" DIA
47 W500-0077 FIRESTOP / WALL PLATE
48 W020-0032 HARDWARE
49 BRTC7 BRASS TRIM COLLAR
50 BM6724 24" STOVE PIPE - 7" DIAMETER
51 W010-0300 10' ALUMINUM FLEX LINER C / W SPACERS - 4" DIA
52 W025-0001 DECORATIVE BRASS BAND
GD180 PERISCOPE
44 BM6790 90° ELBOW - 7" DIAMETER
53 GD201 PERISCOPE
46 BM67ADJ 30" TO 53" ADJUSTABLE PIPE - 7" DIA
47 W500-0077 FIRESTOP / WALL PLATE
48 W020-0032 HARDWARE
49 BRTC7 BRASS TRIM COLLAR
50 BM6724 24" STOVE PIPE - 7" DIAMETER
51 W010-0300 10' ALUMINUM FLEX LINER C / W SPACERS - 4" DIA
52 W025-0001 DECORATIVE BRASS BAND
GD110 - 1/12 TO 7/12 PITCH
54 W010-0569 AIR TERMINAL
55 W120-0036 VERTICAL CAP
56 W010-0567 ROOF SUPPORT
57 W263-0054 ROOF FLASHING
58 W170-0052 STORM COLLAR
GD111 - 8/12 TO 12/12 PITCH
54 W010-0569 AIR TERMINAL
55 W120-0036 VERTICAL CAP
56 W010-0067 ROOF SUPPORT
57 W263-0055 ROOF FLASHING
58 W170-0052 STORM COLLAR
GD112 - FLAT ROOF
54 W010-0569 AIR TERMINAL
55 W120-0036 VERTICAL CAP
56 W010-0567 ROOF SUPPORT
57 W263-0056 ROOF FLASHING
58 W170-0063 STORM COLLAR
Contact your dealer or the factory for questions concerning
prices and policies on replacement parts. Normally all parts
can be ordered through your Napoleon dealer or distributor.
When ordering replacement parts always give the follow-
ing information: 1. M ODEL & S ERIAL N UMBER OF FIREPLACE
2. I NSTALLATION DATE OF FIREPLACE
3. P ART N UMBER
4. D ESCRIPTION OF PART
5. F INISH
FOR FOR FOR FOR FOR WARRANTY WARRANTY WARRANTY WARRANTY WARRANTY REPL REPL REPL REPL REPLA A A A ACEMENT CEMENT CEMENT CEMENT CEMENT P P P P PAR AR AR AR ARTS TS TS TS TS , , , , ,
A A A A A PHO PHO PHO PHO PHOT T T T TOCOPY OCOPY OCOPY OCOPY OCOPY OF OF OF OF OF THE THE THE THE THE
ORIGINAL ORIGINAL ORIGINAL ORIGINAL ORIGINAL INVOICE INVOICE INVOICE INVOICE INVOICE WILL WILL WILL WILL WILL BE BE BE BE BE REQUIRED REQUIRED REQUIRED REQUIRED REQUIRED TO TO TO TO TO HONOUR HONOUR HONOUR HONOUR HONOUR THE THE THE THE THE CLAIM CLAIM CLAIM CLAIM CLAIM .....
REPLACEMENTS
*
IDENTIFIES ITEMS WHICH ARE NOT ILLUSTRATED
.
FOR
FURTHER INFORMATION
,
CONTACT YOUR NAPOLEON
DEALER
.
TERMINAL KITS
ROOF TERMINAL KITS
COMPONENTS COMMON TO BOTH UNITS:
# PART # DESCRIPTION
1 W725-0028 RBT SHAW VALVE - NG
1 W725-0029 RBT SHAW VALVE - LP
2 W100-0046 TURBO REAR BURNER
3 W100-0040 FRONT BURNER
4 W455-0037 #43 REAR BURNER ORIFICE - NG
4 W455-0034 #57 REAR BURNER ORIFICE - LP
4 W455-0043 #45 REAR BURNER ORIFICE - H I A LT NG
4 W455-0035 #59 REAR BURNER ORIFICE - H I A LT LP
5 W455-0045 #34 FRONT BURNER ORIFICE - NG
5 W455-0033 #53 FRONT BURNER ORIFICE - LP / H I A LT LP
5 W455-0044 #36 FRONT BURNER ORIFICE - H I A LT NG
6 W010-0800 PILOT ASSEMBLY - LP
6 W010-0801 PILOT ASSEMBLY - NG
7 W455-0068 PILOT INJECTOR - LP
7 W455-0070 PILOT INJECTOR - NG
8 W680-0005 THERMOCOUPLE
9 W680-0004 THERMOPILE
10 W290-0029 PILOT GASKET
11 W380-0001 TURBO CONTROL KNOB
12 W010-0087 TURBO VALVE - NG
12 W010-0175 TURBO VALVE - LP
13 GS-530K BLACK TRIVET
14 W573-0008 HIGH TEMPERATURE SEALANT
15 W357-0001 PIEZO IGNITOR
16 W715-0195 PEDESTAL TRIM
17 GL-642 LOG SET
18 W135-0194 BASE LOG (#1)
19 W135-0195 MIDDLE CROSSOVER LOG (#2)
20 W135-0196 RIGHT CROSSOVER LOG (#3)
21 W135-0197 LEFT CHUNK (#4)
22 W135-0027 CHARCOAL EMBER STRIP
23 W290-0030 BURNER GASKET
24 W562-0022 GLASS GASKET
25 W385-0245 NAPOLEON LOGO
26 W300-0029 FRONT WINDOW GLASS
27 W030-0021 ACCENT BAR
28 W300-0028 SIDE WINDOW GLASS
29 GDS63 BLOWER c/w GASKET
30 W225-0086G DOOR (FRAME ONLY)
31 W010- 0715G GOLD DOOR COMPLETE
32 W290-0032 RELIEF HOUSING GASKET
33 W430-0002 MAGNETIC CLOSURE
34 W290-0031 AIR MANIFOLD GASKET
35 W390-0001 LATCH
36 W750-0009 ELECTRODE WIRE
37 W660-0009 ON/OFF SWITCH
38 W690-0002 THERMODISC
39 W434-0001 MIRROR
40 W500-0111 COMBUSTION AIR COVER PLATE
41 W290-0033 COMBUSTION AIR GASKET
42 W380-0002 VARIABLE SPEED SWITCH KNOB
43 KB-35 VARIABLE SPEED SWITCH
44 W010-0459 ADAPTER C / W SPILL SWITCH
45 W660-0006 SPILL SWITCH
46 W060-0003 TERMINAL BLOCK
47 W025-0001 DECORATIVE BRASS BAND
42 W380-0002 VARIABLE SPEED SWITCH KNOB
43 KB-35 VARIABLE SPEED SWITCH
GDS50 COMPONENTS
GS50 COMPONENTS
# PART # DESCRIPTION
59 GS-530G GOLD PLATED TRIVET
60 W690-0001 MILLIVOLT THERMOSTAT
61 W660-0011 REMOTE CONTROL - ADVANTAGE PLUS
62 BM6745 45° ELBOW
63 GD301 HEAT GUARD
64 W175-0001 4" COUPLER
53 GD201 PERISCOPE
65 GS-150KT ADAPTER KIT
ACCESSORIES:
GDS50 ACCESSORIES
GS50 ACCESSORIES
