Parts Breakdown - Exploded View - Rev E
29
REF PART# DESCRIPTION
QTY
REF PART# DESCRIPTION
QTY
1
780405 Cylinder, 4” x 24”
1
29
30289
¾” Suction Hose
17”
2
50RAS8 ½” NPT Elbow
7
30
50NBR12 ¾” NPT x ¾” hose barb elbow
1
3
777341 Hydraulic Hose, ½” x 25”
2
31
4011
Suction Strainer
1
5
50CSC128 ¾” NPT x ½” NPT Reducer
2
32
779200 Towbar and Axle/Tank
1
8
39238
Control Valve
1
33
779190 6.5 HP Briggs Engine
1
9
406518 1” x 3” Pin
2
34
1176
3/8” x 3 3/8” Hitch Pin
3
10 780975
Beam
1
35 38445 Support
leg
2
11
777799 Tire
2
36
406519 1” x 5” Pin
1
12
30028
Axle Nut
2
37
405A
Breather cap
1
13
124A
Dust Cap
2
45
82115
7/16” Nut
8
14
780976 Hydraulic Hose ½” x 48”
1
46
82114
7/16 x 2” Grade 8 Bolt
8
18 38587
2”
Coupler
1
47 37024
Keeper
plate
2
19
1130
Safety Chain
2
48
37025
Keeper spacer
2
22 17141
Hose
Clamp
2
49 38436
Wedge
1
23
1012
Pump
1
50
82140
1/8” x 2” Cotter Pin
3
24
3002
Coupling, ½”
1
51
30312
1/8” Bridge Pin
3
25 3009
Coupling
insert
1
52 38896
Hoop
1
26 777885
Coupling
7/8”
1
53 778319
Love-Joy
Shield
1
28
780977 Hydraulic Hose ½”x 72”
1
