Parts Explosion Rev. F.2
Item Part#
Description
Qty Model
1 779827
35811
35812
779828
38518
779829
777654
778164
38520
781210
781209
Comet VRX Pump
General TP 2530
General EZ3040
Comet BXD Pump
Cat 3DX Pump
Comet AXD Pump
Cat 3SP Pump
Comet ZWD Pump
Cat 66DX Pump
NorthStar NSLW
NorthStar NSZW
1
1
1
1
1
1
1
1
1
1
1
A1577541
A1573701
A1573981
A1578111
A1578171
A1578131
A1578181
A1578151
A1578201
A1578173
A1578203
2 777915
Quick
Connect
Outlet Plug
1 all
3 4027
38596
35169
Inlet Filter
Inlet Filter
Inlet Filter
1
1
A1577541, 3701,
3981,8111,8131,
8151,8173,8203
A1578171,818
A1578201
4
777340
¼” x ¼” Hose Barb
Fitting
1 A1578171,8181,
8201
5
777834
¼” Hose Clamp
2
A1578171,8181,
8201
Item Part#
Description
Qty Model
6
777165
¼” PVC Hose
14”
A1578171,8181,
8201
7
38584
Easy Start Valve
1
A1578171,8181,
8201
8 777347
3/8”
Street Tee
1
A1578171,8181
8201
9 35918
777836
Thermal Valve
Thermal Valve
1
1
A1578171,8181
A1578201,3701,
3981
10 22393
35814
782121
Pop Off Valve
Pop Off Valve
Pop Off Valve
1
1
1
A1578181,8201
A1573701
A1573981
18 35813
Manifold
Inlet
1 A1573701,3981
19 82141
82142
82143
3/16” x 1.5” Shaft Key
3/16” x 2” Shaft Key
¼” x 1 ¾” Shaft key
1
1
1
A1578171
A1573701
A1578181,8131,
3981,8151,8201
20
777165
¼” Chemical Hose
3ft
all
21 221222
Chemical
Strainer
1
all
22 777837
3/8”
plug
1
A1578181
