MultiSync LCD 60 Series Specifications
MultiSync LCD1560V
15"
.297mm
85.5 @ native resolution
250cd/m
2
400:1
100 Vert., 120 Hor.
(45U/55D/60L/60R)
40ms
More than 16 million
31.5-60 kHz
56.2-75.1 Hz
ANALOG 0.7 Vp-p /75 Ohms
Separate sync: TTL Level
(Positive/Negative)
VGA 15 pin D-Sub
ANALOG
720 x 400 @ 70 Hz
640 x 480 @ 60-75 Hz
800 x 600 @ 56-75 Hz
832 x 624 @ 75 Hz
1024 x 768 @ 60-75.1 Hz
1024 x 768 @ 75 Hz
Thin-frame (bezel), No Touch
Auto Adjust, NaViSet soft-
ware, AccuColor color control,
3rd party touchscreen and
protective glass integration,
digital smoothing, digital
controls, Plug and Play (VESA
DDC 2B/DDC-CI), VESA DPMS
power management, user (OSM)
controls, ISO 13406-2 Class II,
Vacation Switch
yes
.8 @ 100-120v, .4 @ 220-240V
22W
2W
13.6 x 13.6 x 6.5 in./
344.8 x 344.2 x 166mm
13.6 x 11 x 2.3 in./
344.8 x 279 x 58mm
8.2 lbs/3.7 kg
6.2 lbs./2.8 kg
75mm x 75mm
5-35 C/41-95 F
30-80%
3,048m/10,000 ft.
-10-60 C/14-140 F
10-85%
12,192m/40,000 ft.
3 years parts and labor,
including backlight
24 hours/7 days
MultiSync LCD1560M
15"
.297mm
85.5 @ native resolution
300cd/m
2
450:1
110 Vert., 150 Hor.
(50U/60D/75L/75R)
Rapid Response (25ms)
More than 16 million
31.5-60 kHz
56.2-75.1 Hz
ANALOG 0.7 Vp-p /75 Ohms
Separate sync: TTL Level
(Positive/Negative)
DVI-D and VGA 15 pin D-Sub
ANALOG/DIGITAL
720 x 400 @ 70 Hz
640 x 480 @ 60-75 Hz
800 x 600 @ 56-75 Hz
832 x 624 @ 75 Hz
1024 x 768 @ 60-75.1 Hz
1024 x 768 @ 75 Hz
Thin-frame (bezel), No Touch
Auto Adjust, NaViSet soft-
ware, sRGB, 4-port USB 2.0
hub, bezel-integrated speakers,
AccuColor color control, digital
smoothing, digital controls,
Plug and Play (VESA DDC
2B/DDC-CI), VESA DPMS power
management, user (OSM) con-
trols, ISO 13406-2 Class II,
Vacation Switch
no
.8 @ 100-120v, .4 @ 220-240V
35W
2W
13.6 x 13.6 x 6.5 in./
344.8 x 344.2 x 166mm
13.6 x 12.1 x 2.5 in./
344.8 x 306.1 x 63mm
9.7 lbs/4.4 kg
TBD
75mm x 75mm
5-35 C/41-95 F
30-80%
3,048m/10,000 ft.
-10-60 C/14-140 F
10-85%
9,601m/31,500 ft.
3 years parts and labor,
including backlight
24 hours/7 day
MMultiSync LCD1560NX
15"
.297mm
85.5 @ native resolution
250cd/m2
350:1
90 Vert., 120 Hor.
(45U/45D/60L/60R)
Rapid Response (30ms)
More than 16 million
31.5-60 kHz
56.2-75.1 Hz
ANALOG 0.7 Vp-p /75 Ohms
Separate sync: TTL Level
(Positive/Negative)
DVI-D and VGA 15 pin D-Sub
ANALOG/DIGITAL
720 x 400 @ 70 Hz
640 x 480 @ 60-75 Hz
800 x 600 @ 56-75 Hz
832 x 624 @ 75 Hz
1024 x 768 @ 60-75.1 Hz
1024 x 768 @ 75 Hz
Thin-frame (bezel), No Touch
Auto Adjust, NaViSet soft-
ware, AccuColor color control,
3rd party touchscreen and
protective glass integration,
digital smoothing, digital
controls, Plug and Play (VESA
DDC 2B/DDC-CI), VESA DPMS
power management, user (OSM)
controls, ISO 13406-2 Class II,
Vacation Switch
yes
.8 @ 100-120v, .4 @ 220-240V
20W
2W
13.6 x 13.6 x 6.5 in./
344.8 x 344.2 x 166mm
13.6 x 11 x 2.3 in./
344.8 x 279 x 58mm
8.2 lbs/3.7 kg
6.2 lbs./2.8 kg
75mm x 75mm
5-35 C/41-95 F
30-80%
3,000m/9,843 ft.
-10-60 C/14-140 F
10-85%
12,000m/39,370 ft.
3 years parts and labor,
including backlight
24 hours/7 days
MultiSync LCD1760V
17"
.264mm
96.2 @ native resolution
260 cd/m
2
400:1
140 Vert., 140 Hor.
(70U/70D/70L/70R)
Rapid Response (30 ms)
More than 16 million
31.5-80 kHz
56-75 Hz
Analog 0.7 Vp-p/75 Ohms
Separate sync: TTL Level
(Positive/Negative)
Composite sync: TTL Level
(Positive/Negative)
Composite sync on green:(0.3
Vp-p negative 0.7 Vp-p positive)
VGA 15 pin D-sub
ANALOG
720 x 400 @ 70 Hz
640 x 480 @ 60-75 Hz
800 x 600 @ 56-75 Hz
832 x 624 @ 75 Hz
1024 x 768 @ 60-75 Hz
1152 x 870 @ 75 Hz
1280 x 1024 @ 60-76 Hz
1280 x 1024 @ 60 Hz
Thin-frame (bezel), No Touch
Auto Adjust, NaViSet software,
sRGB, LiquidView, AccuColor color
control, 3rd party touchscreen
and protective glass integra-
tion, digital smoothing, digital
controls, Plug and Play (VESA
DDC 2B/DDC-CI), VESA DPMS
power management, user (OSM)
controls, ISO 13406-2 Class II,
Vacation Switch
yes
.8 @ 100-120v, .4 @ 220-240V
38W
2W
14.7 x 15.1 x 7.7 in./
374 x 383.6 x 196mm
14.7 x 12.6 x 2.5 in./
374 x 318.8 x 63.5mm
11.7 lbs./5.3kg
9.3 lbs./4.2kg
100mm x 100mm
5-35 C/41-95 F
10-80%
3,048m/10,000 ft.
-10-60 C/14-140 F
10-85%
9,145m/30,000 ft.
3 years parts and labor,
including backlight
24 hours /7 days
MultiSync LCD1760VM
17"
.264mm
96.2 @ native resolution
220 cd/m
2
400:1
120 Vert., 140 Hor.
(60U/60D/70L/70R)
Rapid Response (25 ms)
More than 16 million
31.5-81.1 kHz
56-75 Hz
Analog 0.7 Vp-p/75 Ohms
Separate sync: TTL Level
(Positive/Negative)
Composite sync: TTL Level
(Positive/Negative)
Composite sync on Green:(0.3
Vp-p negative 0.7 Vp-p positive)
DVI-D and VGA 15 pin D-sub
ANALOG/DIGITAL
720 x 400 @ 70 Hz
640 x 480 @ 60-75 Hz
800 x 600 @ 56-75 Hz
832 x 624 @ 75 Hz
1024 x 768 @ 60-75 Hz
1152 x 870 @ 75 Hz
1280 x 1024 @ 60-76 Hz
1280 x 1024 @ 60 Hz
Thin-frame (bezel), No Touch
Auto Adjust, NaViSet soft-
ware, sRGB, LiquidView,
AccuColor color control, bezel-
integrated speakers, digital
smoothing, digital
controls, Plug and Play (VESA
DDC 2B/DDC-CI), VESA DPMS
power management, user (OSM)
controls, ISO 13406-2 Class II,
Vacation Switch
no
.8 @ 100-120v, .4 @ 220-240V
48W
2W
14.7 x 15.1 x 7.7 in./
374 x 383.6 x 196mm
14.7 x 13.6 x 2.5 in./
374 x 345.9 x 63.5mm
13 lbs./5.9kg
10.4 lbs./4.7kg
100mm x 100mm
5-35 C/41-95 F
10-80%
3,000m/9,843 ft.
-10-60 C/14-140 F
10-85%
12,000m/39,370 ft.
3 years parts and labor,
including backlight
24 hours /7 days
MultiSync LCD1760NX
17"
.264mm
96.2 @ native resolution
260 cd/m
2
400:1
140 Vert., 140 Hor.
(70U/70D/70L/70R)
Rapid Response (30 ms)
More than 16 million
31.5-80 kHz
56-75 Hz
Analog 0.7 Vp-p/75 Ohms
Separate sync: TTL Level
(Positive/Negative)
Composite sync: TTL Level
(Positive/Negative)
Composite sync on green:(0.3
Vp-p negative 0.7 Vp-p positive)
DVI-D and VGA 15 pin D-sub
ANALOG /DIGITAL
720 x 400 @ 70 Hz
640 x 480 @ 60-75 Hz
800 x 600 @ 56-75 Hz
832 x 624 @ 75 Hz
1024 x 768 @ 60-75 Hz
1152 x 870 @ 75 Hz
1280 x 1024 @ 60-76 Hz
1280 x 1024 @ 60 Hz
Thin-frame (bezel), No Touch
Auto Adjust, NaViSet software,
sRGB, LiquidView, AccuColor
color control, 3rd party touch-
screen and protective glass
integration, digital smoothing,
digital controls, Plug and Play
(VESA DDC 2B/DDC-CI), VESA
DPMS power management, user
(OSM) controls, ISO 13406-2
Class II, Vacation Switch
yes
.8 @ 100-120v, .4 @ 220-240V
38W
2W
14.7 x 13.5 x 8.1 in./
374 x 343.8 x 205mm
14.7 x 12.6 x 2.5 in./
374 x 318.8 x 63.5mm
13.9 lbs./6.3kg
9.3 lbs./4.2kg
100mm x 100mm
5-35 C/41-95 F
10-80%
3,048m/10,000 ft.
-10-60 C/14-140 F
10-85%
9,145m/30,000 ft.
3 years parts and labor,
including backlight
24 hours /7 days
MultiSync LCD1860NX
18.1"/46cm
.281mm
90.4 @ native resolution
200 cd/m
2
350:1
160 Vert., 160 Hor.
(80U/80D/80L/80R)
Rapid Response (30 ms)
More than 16 million
31-82 kHz (ANALOG)
31-80 kHz (DIGITAL)
55-85 Hz
Analog 0.7 Vp-p/75 Ohms
Separate sync: TTL Level
(Positive/Negative)
Composite sync: TTL Level
(Positive/Negative)
Composite sync on Green:(0.3
Vp-p negative 0.7 Vp-p positive)
DVI-D and VGA 15 pin
ANALOG/DIGITAL
640 x 400 @ 70 Hz
720 x 400 @ 70 Hz
640 x 480 @ 60 Hz-85 Hz
800 x 600 @ 56 Hz-85 Hz
832 x 624 @ 75 Hz
1024 x 768 @ 60 Hz-85 Hz
1152 x 870 @ 75 Hz
1280 x 1024 @ 60 Hz
(60-75 Hz for ANALOG)
1280 x 1024 @ 60 Hz
Thin frame (bezel), XtraView
Technology wide-angle viewing,
DDC/CI, No Touch Auto Adjust,
OmniColor,(for sRGB color
setting), 3rd party touchscreen
and protective glass integra-
tion, digital smoothing, digital
controls, Color control (4 mode
memory + sRGB + NATIVE), Plug
and Play (VESA DDC 2B/DDC-CI),
VESA DPMS power management,
User OSM controls, Cable
Management, Vacation Switch,
Internal Power Supply, swivel at
neck of stand base, black level
adjustment + 10 bit gamma
yes
.8 @ 100-120v, .4 @ 220-240V
38W
3W
15.7 x 15.9 x 7.9 in./
398mm x 402.8mm x 200mm
15.7 x 13.5 x 2.9 in./
398mm x 342.5mm x 73.5mm
16.1 lbs./7.3kg
13.7 lbs./6.2kg
100mm x 100mm
5C-35C/41F-95F
30%-80%
3,658m/12,001 ft.
-20C-60C/-4F-140F
10%-90%
16,255m/53,330 ft.
3 years parts and labor,
including backlight
24 hours /7 days
Model
Display:
Viewable Image Size
Pixel Pitch
Pixels Per Inch
Brightness (typical)
Contrast Ratio (typical)
Viewing Angle
Response Time
Display Colors
Synchronization Range:
Horizontal
Vertical
Input Signal:
Video
Sync
Input
Resolutions Supported
Native Resolution
Additional Features
Touch-Capable
Voltage Rating
Power Consumption:
On
Power Savings Mode
Dimensions (WxHxD):
Net (with stand)
Net (without stand)
Net Weight
(with stand)
(without stand)
VESA Hole Configuration
Specifications
Environmental Conditions:
Operating Temperature
Operating Humidity
Operating Altitude
Storage Temperature
Storage Humidity
Storage Altitude
Limited Warranty
Technical Support
All specifications are the same for all models unless otherwise
noted. OSM and XtraView are registered trademarks and
Integration Select, NaViSet, No Touch Auto Adjust, OmniColor,
RapidResponse and See More are trademarks of NEC-Mitsubishi.
MAC and Macintosh are registered trademarks of Apple
Computer, Inc. All other brand or product names are trademarks or
registered trademarks of their respective holders. Product specifi-
cations subject to change.
11/02 ver.1.
