Anti-lock Braking System (ABS) warning
light
Master warning light Security indicator light
Seat belt warning light and chime Slip indicator light
Automatic transmission check warning light* Supplemental air bag warning light Small light indicator light
Brake warning light
Transmission position indicator* Soft top indicator light (Roadster models)
Cruise indicator light
SynchroRev Match mode (S-MODE) indi-
cator*
Charge warning light Front passenger air bag status light Turn signal/hazard indicator lights
Engine oil pressure warning light High beam indicator light
Vehicle Dynamic Control (VDC) off indicator
light
Intelligent Key system warning light Malfunction Indicator Light (MIL) *: if so equipped
Low tire pressure warning light Rear fog light indicator light*
CHECKING BULBS
With all doors closed, apply the parking brake
and push the ignition switch to the ON position
without starting the engine. The following lights
will come on (if so equipped):
, or , , ,
The following lights come on briefly and then go
off (if so equipped):
, or , , , , ,
If any light does not come on, it may indicate a
burned-out bulb or an open circuit in the
electrical system. Have the system checked by
a NISSAN dealer.
Some indicators and warnings are also dis-
played on the vehicle information display. (See
“VEHICLE INFORMATION DISPLAY” later in
this section.)
WARNING/INDICATOR LIGHTS AND
AUDIBLE REMINDERS
2-8 Instruments and controls
