C5-vga

I N S T A L L A T I O N G U I D E

C5-VGA

FOR PLACING VGA VIDEO DEVICES EXTENDED
DISTANCES FROM THE VGA VIDEO SOURCE

C A T - 5 V G A B A L U N

CONGRATULA

TIONS!

Thank you for choosing the

C5-VGA Balun

from Niles. With proper installa

tion and operation,

you’ll enjoy years of trouble free use.

Niles manufacturers the industry’

s most complete line of custom installation components and

accessories for audio/video systems. To see the complete assortment,

visit our website at

www.nilesaudio.com.

INTRODUCTION

The C5-VGA is a stand-alone device that transforms a

VGA video signal to and from CAT-5

twisted pair cabling. It has two sets of simple connections.

The ﬁrst is a DB-15HD connector

that connects to the

VGA video source or VGA video display device.

The second is a shielded

CAT-5 connector for the CA

T-5 twisted pair connection.

The C5-VGA is normally used as a pair

Both ends are identical. The circuitr

y is passive so there is no need for a power supply

The C5-VGA allows a computer monitor or other

VGA video device to be located an extended

distance from the system it is to be connected to. Doing so with conventional monitor cabling

is both expensive and prone to signal degradation.

By using a pair of these devices and a run

of CAT-5 the problem can be solved inexpensively and without signal loss and the introduction

of noise. In addition,

in today’s retroﬁt market an installer cannot al

ways successfully run a

wire from point A to point B.

There exists ho

wever an abundance of twisted pair cabling in

many homes.

By using a pair of these devices with an existing wire an installer may be able to

complete a job that he otherwise could not.

FEATURES

• Shielded CAT-5 Connector

• DB-15HD Connector

• Universal Mounting Holes

• Ten-y

ear limited warr

anty

SPECIFICATIONS

• Overall dimensions:

4.75" W x .85" H x 2" D

• Bandwidth: 0 – 50 MHz,

-3 dB

• Tr

ansmission Distance:

CAT-5 STP:

640 x 480 pixels (15 MHz):

> 330' (> 100 m)

800 x 600 pixels,

60Hz refr

esh, (30 MHz):

> 330' (> 100 m)

1024 x 768 pixels,

75Hz refr

esh, (60 MHz):

> 250' (> 75 m)

1280 x 1024 pixels, 75Hz r

efresh,

(100 MHz): > 160' (> 50 m)
