NAD 1300 User Manual
Page 2
PRE-AMP SECTION
Phono input
Input impedance
(R and C)
MM
47k
Ω
/ 200pF
MC
100
Ω
/ 1000pF
Input sensitivity, 1kHz
MM
1.3mV ref. 0.5V
MC
60µV ref. 0.5V
Input overload at 20Hz / 1kHz / 20kHz
MM
20 / 200 / 2000mV
MC
1.0 / 10 / 100 mV
Signal/Noise ratio
(A-weighted with cartridge connected)
MM
80dB ref. 5mV
MC
78dB ref. 0.5mV
THD
(20Hz - 20kHz)
<0.02%
RIAA response accuracy
±0.3dB
(20Hz - 20kHz)
Line level inputs
Input impedance
(R and C)
100k
Ω
/ 220pF
Input sensitivity ref. 0.5V
80mV
Maximum input signal
12V
Signal/Noise ratio
(A-weighted ref 0.5V)
>100dB
Frequency response
±0.3dB
Line level outputs
Output impedance
Normal
50
Ω
Tape or EPL
1k
Ω
High Level
100
Ω
Phones
70
Ω
Maximum output level
Tape, Normal & EPL
12V
High & headphones
15V
Tone controls
Treble
±12dB at 3, 6, or 12kHz
Bass
±12dB at 50, 120 or 250Hz
Bass EQ
+3dB at 55Hz
+6dB at 36Hz
Infasonic filter
(switchable)
-3dB at 14Hz, 18dB/octave
Remote
No
NAD Link
No
PHYSICAL SPECIFICATIONS
Dimensions (W x H x D)
435 x 84 x 273mm
Net weight
4.3kg
Shipping weight
5kg
Power consumption (120 ~ 240V, 50/60Hz)
20W
Dimensions are of unit’s cabinet without attached feet; add up to 18mm for total height.
Dimension depth excludes terminals, sockets, controls and buttons.
