® 2008 N-TRON, Corp. N-TRON and the N-TRON logo are trademarks of N-TRON, Corp. Product names mentioned herein are for identification purposes only
and may be trademarks and/or registered trademarks of their respective company. Specifications subject to change without notice. Printed in USA.
BENEFITS
SPECIFICATIONS
REV 080617
Industrial Network Switch
•
Compact Size / Smaller Footprint
•
Extended Environmental Specifications
•
Hardened Metal DIN-Rail Enclosure
•
High Performance
•
High MTBF >2M Hours
•
ESD Protection Diodes on RJ-45 Ports
•
Surge Protection Diodes on Power Inputs
Contact Information
Ordering Information
104TX
Four 10/100BaseTX Ports
NTPS-24-1.3
DIN-Rail Power Supply
[email protected] Amp
Physical
Height:
2.88"
(7.31cm)
Width:
1.50"
(3.81 cm)
Depth:
3.55" (9.02 cm)
Including DIN-Rail Mount:
4.25"
(10.8 cm)
Weight:
0.54 lbs. (0.25 kg)
DIN-Rail:
35mm
Electrical
Input Voltage:
10-30 VDC
Steady Input Current:
215mA@24V
Inrush:
7.8Amp/0.7ms@24V
Environmental
Operating Temperature:
-40
o
C to 80
o
C
Storage Temperature:
-40
o
C to 85
o
C
Operating Humidity:
10% to 95%
(Non Condensing)
Operating Altitude:
0 to 10,000 ft.
Reliablity
MTBF:
>2 Million Hours
Network Media
10BaseT:
>Cat3 Cable
100BaseTX:
>Cat5 Cable
Connectors
10/100BaseTX:
Four (4) RJ-45 TX
Copper Port
Recommended Wiring Clearance
Front:
2" (5.08 cm)
Top:
1" (2.54 cm)
Regulatory Approvals
FCC Title 47 Part 15 Class A,
CE: EN61000-6-2,4, EN55011, EN61000-4-2,3,4,5,6
UL Listed (US and Canada) per ANSI/ISA-12.12.01-2000
Class I, Div. 2 Groups A,B,C,D,T4A, GOST-R Certified,
RoHS Compliant, Submitted for type approval from ABS
for Shipboard Applications
Designed to comply with:
IEEE 1613 for Electric Utility Substations,
and NEMA TS1/TS2 for Traffic Control Equipment
Ease of Use
•
Plug & Play Operation
•
Auto Sensing 10/100BaseTX
•
Auto Negotiation Full/Half Duplex
•
MDIX Auto Cable Sensing
•
Unmanaged Operation
Increased Performance
•
Full Wire Speed Capable
•
Full Duplex Capable
•
Eliminates Network Collisions
•
Increases Network Determinism
N-TRON Corp.
820 S. University Blvd.,
Suite 4E
Mobile, AL 36609 USA
TEL: (251) 342-2164
FAX: (251) 342-6353
Website: www.n-tron.com
Email: [email protected]
N-TRON Europe GmbH
Alte Steinhauserstr 19
6330 Cham / Zg
Switzerland
TEL: +41 41 7406636
FAX: +41 41 7406637
