Pro-8a 2400 Air – Pro-8a 1200 Air
14
www.profoto.com
5. View power in W/s or Relative F-Stops. Press & release Ws button [1] for 5 sec, to toggle
flash energy setting. 2 beeps confirm change.
6. 1/10th f-stop flash adjustment. Rotate corresponding control dial clockwise to raise
power or counter clockwise to lower. Each click represents 1/10th f-stop. Three quick
beeps indicate power can not be raiser or lowered further.
7. Full F-Stop Flash Adjustment. Press down while rotating correspondence control dial
clockwise to raise power or counter clockwise to lower. Each click represents 1 f-stop.
Three quick beeps indicate power can not be raiser or lowered further.
Settings
1. Use the Modeling Light Control [7] to select MAX PROP, MAX, PROP or ½ PROP. Press the
Modeling Light switch [9] to turn on the modeling light.
2. Use Flash Light Energy Control A [8] and B [19] to set the energy levels.
3. Use the Ready Control [16] to select BEEP-DIM, BEEP, DIM or OFF.
4. Use the Speed Control [18] to select MAX, 75%, 50% or 25%.
Sync via cable
1. Connect a sync cord from the camera to one of the Sync Connectors [2] on the generator.
Sync via cable+flash meter
1. Connect a sync cord from the camera to one of the Sync Connectors [2] on the generator.
2. Connect another sync cable from the flash meter to the free Sync Connector [2].
Sync via Photocell / ir-slave
1. Connect an IR transmitter to the camera.
2. Turn the Sync Control [5] to SLAVE.
Sync via radio (Profoto Air)
1. Connect an Air Remote or Air Sync unit to the camera.
2. Turn the Sync Control [5] to RADIO.
3. Pro-8a is now ready to flash, with the selected radio channel.
