Speakers connections, User manual: see pages 12–16 – Philips LX7500R/05 User Manual
Page 3
3
Speakers
Connections
➜
User manual: see pages 12–16
VIDEO OUT COMPONENT
FOR PLAYBACK
Front left
Front right
Center
Subwoofer
Rear left
Rear right
Front left
Front right
Center
Subwoofer
Rear left
Rear right
After finishing all other connections connect
the mains cable to the wall socket.
FM
antenna
cable
TV
antenna
cable
