8A.ONCE A WEEK

1. Clean Razor Head Assem-

bly as shown (Fig. 4).

2. Lift Razor Head Assembly

using thumb and index
finger to remove from
razor housing (Fig. 5).

3. Clean inside of Razor

H e a d A s s e m b l y a n d
Hair Chamber with long
bristles of brush.

4. Press Razor Head Assem-

bly back on razor hous-
ing.

IMPORTANT:

Do NOT

interchange the cutters and
combs. They are a matched set
and if interchanged may ad-
versely affect shaving perfor-
mance until cutters reseat them-
selves. Therefore, remove, clean,
and replace each set individually.
1. Remove Razor Head

Assembly (Fig. 5).

2. While holding Razor Head

Assembly in one hand,
press center wheel down
while turning counterclock-
wise to release frame and
lift out. Set frame aside
(Fig. 6).

3 . S l i d e o n e c u t t e r /

comb, at a time, out of
frame as shown (Fig. 7).

4. Cutter should be held as

shown and brushed in an
upward motion (Fig. 8).
Clean inside of comb
with long bristles of
b r u s h i n a c i r c u l a r
motion.

5. For consistently close and

comfortable shaves, razor
heads should be cleaned
and lubricated every 4-8
weeks. Cleaning heads
in a degreasing liquid
(e.g. Norelco Razor
Cleaner, RAZORMATE
Electrosonic Cleaner or
alcohol).

6. Replace cutter into comb

section. Slide cutting head
back into frame making
sure that flat rim of cutting
head slides under 2
clamps on frame.

7. Repeat procedure for

other two cutting heads.

8. Replace frame, with cutting

heads in place, back
into Razor Head
Assembly. While press-
ing down, turn wheel
clockwise to lock frame
into place (Fig. 9).

9. Press Razor Head Assembly

back on razor housing.

10. Spread Norelco Razor

Lubricant, model AL80,
or one drop of mineral
oil over floating heads
with your finger.

9. HQ4 REPLACE-

MENT HEADS
AND RAZOR
ACCESSORIES

Replacement Heads:
The self-sharpening rotary
blades in your Norelco
razor are precision-made to
give closer shaves. When
they finally do need replac-
ing, specify only Norelco
brand replacement cutters
and combs, model HQ4.
DO NOT USE

shaver

sharpeners as this will
damage your blades and
lifters and will adversely
affect the shaving perfor-
mance.
NOTE:

It is recommended

that you replace your razor
heads once a year.
Razor Cleaners:
Norelco RAZORMATE Electro-
sonic Heads Cleaner, model
ERC100.
Norelco Razor Cleaner,
model RC1776.
Norelco Razor Lubricant,
model AL80.
Norelco Razor Accessories
may be purchased at a
store near you, an
Authorized Norelco Service
Location, or by using the
handy order form enclosed.

10. IMPORTANT

BATTERY
DISPOSAL
INFORMATION

When discarding your razor:

THIS NORELCO RAZOR
CONTAINS NICKEL-CAD-
MIUM RECHARGEABLE
BATTERIES WHICH MUST
BE RECYCLED OR DIS-
POSED OF PROPERLY.
Refer to enclosed instruc-
tion sheet for directions on
removing rechargeable bat-
teries.

CAUTION:

■

Batteries should be re-
moved by consumer
only when razor is to
be discarded.

■

Make sure razor is un-
plugged before disman-
tling for battery
removal.

■

All servicing or battery
replacement should be per-
formed by an Authorized
Norelco Service Location
only.

8B.ONCE EVERY 4-8 WEEKS

@@@@@@@@e?

@@h?

@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?

@@@@@@@@

?@@

?@@@@@@@@

?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@

@@g

@@@@@@@@

60-Day Money-Back Guarantee

To enjoy the closest and most comfortable shave from your new
Norelco Men’s Razor, the razor should be used exclusively for 3-4
weeks. This allows your hair and skin enough time to adapt to the
Norelco Shaving System. If, after that period of time, you are not
fully satisfied with your Norelco Men’s Razor, send the product back
and we’ll refund you the full purchase price.

The razor must be shipped prepaid by insured mail, insurance
prepaid, and have the sales receipt, indicating purchase price
and the date of purchase, enclosed. The razor must be post-
marked no later than 60 days after the date of purchase. Norelco
reserves the right to verify the purchase price of the razor and limit
refunds not to exceed suggested retail price.

Send dated sales receipt, your complete name and address as indi-
cated below, and the razor, prepaid to:

Norelco Consumer Products Company

A Division of Philips Electronics North America

Corporation

P.O. Box 1116

Skokie, IL 60076

Please allow 4-6 weeks for delivery of check.

Please Print!

NAME:

ADDRESS:

CITY:

STATE:

ZIP:

TELEPHONE NO.: ( )

REASON FOR RETURNING:

Area Code
