PYLE Audio PPDLWW1 User Manual
Ppdlww1
PPDLWW1
WAH WAH PEDAL
1
2
3
1.
The
SIGNAL OUTPUT
is used
to connect to the amplifi er
2.
The
SIGNAL INPUT
connects
to the instrument
3.
DC9V POWER PLUG
can be
used to power the pedal
4
4.
The
PEDAL
is used to con-
trol the effect
5.
ON/OFF
switch
6. 9 Volt REPLACEABLE BAT-
TERY
SPECIFICATIONS:
5
- Designed for Electronic
Guitars
- Includes Instrumental and
Amplifi er 1/4” Ports
- Rubber Bottom Floor Grips
- Wah Wah Effects Pedal
- True Bypass Switch
- Includes 9V 6F22 replace-
able battery
- Battery Life for Continuous
Use: 100 Hours
- Dimensions: (L) 9 1/4’’ (W) 3
1/2’’ (H) 2 1/2’’
