PET717_93_QSG_V2.0

Philips Portable DVD Player PET717

Quick Start Guide

1

Charge the built-in battery

Step 1 Switch the

POWER ON / OFF/CHR

slide selector to the

OFF/CHR

position.

Step 2 Connect the supplied AC adaptor to the

DC IN 12V

socket

on the DVD Player and to the AC outlet.

The red charge indicator turns on. It takes about 4 hours to fully

charge the battery.
When the battery is fully charged, the red charge indicator turns off.

Tip
-

You can only charge the batter y when the temperature is
between 0°C and 35°C.

-

When headphones are connected to the DVD Player, the fully
charged battery lasts about 2.5 hours
.

2

Install remote control battery

Step 1 Open the battery compartment.
Step 2 Insert 1 CR2025 battery with correct polarity (+/-) as indicated.
Step 3 Close the battery compartment.

CR2025

1

CR2025

2

3

Play discs

Step 1 Lift the display panel.
Step 2 Switch the

OPEN

slide selector to the right to open the disc

compartment.
• (For

the

fi rst time) Remove the protective card.

Step 3 Insert a disc with the printed side facing up.
Step 4 Push the lid down to close the disc compartment.

Disc starts to play automatically. If not, press

OK

or 2; .

If a menu appears, select an item and then press

OK

to start play.

4

Connect a TV

On the DVD Player,
Step 1 Connect the black end of the supplied AV cable to the

AV

OUT

socket.

On the TV,
Step 1 Connect the white end to the left audio input socket and the
red end to the right audio input socket.
Step 2 Connect the yellow end to the video input socket.

TV

I I

VI E I
