Setting up the VoIP SIP phone 27
SmartLink 4050 Series Getting Started Guide 2 • Installing the SmartLink SIP Phone
DISABLE ADSL dialup
1. Press
2. Use to select DISABLE
DHCP (Dynamic Host Configuration Protocol)
DHCP allows the network administrator to distribute IP addresses when a computer is plugged into a different
place in the network. If your ISP provides static IP address, you must disable DHCP and enter the IP
address provided.
ENABLE DHCP
1. Press
2. Use or to set DHCP to ENABLE
3. Press . The IP address is automatically acquired
4. Press . The subnet mask is automatically acquired
5. Press . The router IP address is automatically acquired
DISABLE DHCP
1. Press
2. Use or to set DHCP to DISABLE
3. Press . Use the numeric keypad to enter the IP address
4. Press . Use the numeric keypad to enter the subnet mask
