Pride Mobility Jet 7 User Manual
Page 14
14
www.pridemobility.com
Jet 7
I I I . Y O U R P O W E R C H A I R
YOUR POWER CHAIR
Your power chair has two main assemblies: the seat and the power base. See figure 5. Typically, the seating system
includes the armrests, the seatback, the seat base, and the controller. The power base assembly includes two drive wheels,
two anti-tip wheels, two rear caster wheels, four frame assemblies, two battery boxes, and the electrical connectors. See
figures 5, 6, and 7.
SEATBACK
ANTI-TIP WHEELS
ARMRESTS
FOOT RIGGING
(FOOT PLATFORM SHOWN)
CASTER WHEEL
DRIVE WHEEL
CONTROLLER
SEAT BASE
BODY SHROUD
SEAT ASSEMBLY
Figure 5. The Jet 7
POWER BASE
ASSEMBLY
