SBC

RU970

Full-colour touch-screen display
The ProntoPro, with its large 256-color touch-screen LCD brings
near photo-quality images to interacting with your home
entertainment environment. Add images of users and full-colour
network logos to the intuitive user interface.

Pick it up and the buttons light up
Pick up your ProntoPro and the screen light up straight away -
even before you press it.Tilt sensor backlighting adds extra
convenience to viewing in the dark.

Intelligent remote control
You can customize the user interface to meet your own specific
wishes and personal requirements – and those of all other users
in your home. Add new buttons, redesign the layout, and enhance
the colours. It’s as individual as you are.

Self-learning and a built-in database
With the biggest database of control codes ever built-in to a
universal remote, the ProntoPro can control any other IR remote
controlled product – regardless of brand. It also includes a power-
ful self-learning capability to ensire absolute compatibility with
every IR remote control on the market.

Extended 8 MB memory and macro function
The extended 8 MB memory depth easily holds your graphics,
custom configurations and macros.The unlimited macro facility
allows you to combine as many commands or key-strokes as you
like under a single button. Imagine, just one touch of the colour
screen to close the curtains, dim the lights, start the TV and play
the DVD. Home cinema as it is supposed to be!

Intuitive user interface
You control your complete electronic environment – from home
entertainment products to any other equipment using IR remote
control from the direct-access touch-screen and hardware buttons.
It is supplied with a logically configured standard interface and
you can modify it or create your own using graphics, icons and
menus. ProntoPro’s intuitive controls are extremely user friendly.

Software upgradeable
With ProntoProEdit software, which is supplied on CD-ROM and
freely available on the Internet, you can create configurations, and
download graphics, templates and macros. And the Internet is also
host to independent communities of ProntoPro users.

IR and RF transmission
ProntoPro works with all IR-based remote control links.The optional
RF receivers can be used to use ProntoPro to control audio/video
equipment and accessories anywhere in your home – even
through walls. It’s an intelligent RF link too, filtering out signals
from other wireless devices working at similar frequencies.

Docking station
The recharge docking station keeps your ProntoPro ready for use
at all times. ProntoPro can also be used while docked, and can be
connected to a PC via the docking station.

http://www.pronto.philips.com
http://www.remotecentral.com

Standard product information

• Power supply

Rechargeable AAA battery pack (included)

• Processor

Motorola DragonBall MC68328

• SRAM

512 Kb

• Flash memory

8 Mb

• PC port

RS232 Serial port (3 wire connector)

• Transmission type

IR universal/ RF universal

• Transmission system

Modulated

• Operating distance

IR 10 meters/ RF 50 meters open air

• Transmission angle

30 deg.

• No. direct access buttons

• Audio

Piëzo speaker with adjustable volume

• Weight

250g, with batteries

• Dimensions (mm)

141 x 94 x 32 (L x W x H)

• Environment

Operating temperature (5ºC - 45ºC)
Storage temperature (-25ºC - 70ºC)

• Warranty

1 year European warranty

LCD information

• Display type

FSTN

• Dimension (mm)

77 x 58

• Resolution

320 x 240, 0.24mm pitch

• Position

Portrait

• Refresh rate

70 Hz

• Number of colours

256

• Dynamic LCD input

Finger or blunt object

• EL backlighting

Yes

Installation

• Pre-installed

RC5, RC6 (Philips & Marantz ready)

• Learnable

Yes

• No. of devices

Unlimited (within memory)

• No. of learnable codes

Unlimited (within memory)

• Built-in IR codes

549 brands

• IR learning frequencies

Up to 56 kHz and 455 kHz

Features

• Direct-access buttons

Mute
Channel Up/Down
Volume Up/Down
Right/Left Configuration buttons
Backlight button
2 free programmable buttons

• Customisable User Interface

manual or via PC

Yes

• Software upgradeable

Yes

• Macro functionality

Yes, Unlimited (within memory)

• Timer functionality

Yes, Unlimited (within memory)

• Automatic backlighting

Yes

• LCD Contrast adjustment

Yes

• Auto power on/off

Yes

• Automatic power mgmt

Auto power up/down

Packaging

• Type

Carton box

• Dimensions (mm)

245 x 130 x 210

• Languages

• Languages d.n.y.a.
• 12NC

9082 100 00512

• EAN code

87 10101 67892 4

• Contents

ProntoPro remote control, docking station, serial cable,
instructional manual, rechargeable battery pack and
ProntoProEdit softwarepackage on CD rom

Inner carton

NON

Outer carton

• Contents

• Dimensions (mm)

d.n.y.a.

• Weight (Kg)

d.n.y.a.

• EAN code

87 10101 87202 5
