31 www.pridemobility.com Revo
V I . C O M F O R T A D J U S T M E N T S
SEAT HEIGHT ADJUSTMENT
The seat can be repositioned to one of three different heights. See figure 12.
1. Remove the seat from your scooter. See VII. “Disassembly and As-
sembly.”
2. Use the attached ring to pull and remove the detent pin from the lower
seat post.
3. Raise or lower the upper seat post to the desired seat height.
4. While holding the upper seat post at that height, match up the adjust-
ment holes in the upper and lower seat posts.
5. Fully insert the detent pin.
6. Replace the seat.
Figure 12. Seat Height Adjustment
DETENT
PIN
ADJUSTMENT
HOLES
