14
4. Position the new abrasive pad to the back-up disc, and center the hole of the
disc on the hub (B) Fig. 10 of the back-up disc.
5. Position the large metal washer (B) Fig. 9, and the retaining nut (A) Fig. 9, to
the sander.
6. Rotate the retaining nut clockwise to hand tighten (while holding the abrasive
pad as described in step 1).
TRANSPORTATION AND STORAGE
Keep the sander dry during transport and storage. Protect the abrasive pad.
Contact with another object may deform the pad, causing it to sand unevenly.
If you cannot protect the pad during transport or storage, remove and store it
separately.
A
B
C
B
A
For assistance with your tool, visit our website at www.deltaportercable.com
for a list of service centers, or call the PORTER-CABLE Customer Care Center at
(888)-848-5175.
TROUBLESHOOTING
MAINTENANCE
Fig. 9 Fig. 10
To reduce the risk of injury, turn unit off and disconnect it from
power source before installing and removing accessories, before adjusting or
when making repairs. An accidental start-up can cause injury.
ALWAYS USE SAFETY GLASSES. Everyday eyeglasses are NOT safety
glasses. Also use face or dust mask if cutting operation is dusty. ALWAYS wear certified
safety equipment:
• ANSI Z87.1 eye protection (CAN/CSA Z94.3)
• ANSI S12.6 (S3.19) hearing protection
• NIOSH/OSHA/MSHA respiratory protection.
REPAIRS
For assistance with your tool, visit our website at www.deltaportercable.com for a list of
service centers, or call the PORTER-CABLE Customer Care Center at (888) 848-5175.
CLEANING
Periodically blowing dust and chips out of the motor housing using clean,
dry compressed air is a suggested maintenance procedure. To reduce the risk of seri-
ous personal injury, ALWAYS wear ANSI Z87.1 safety glasses while using compressed
air.
