Specifications, Highlights – Philips AZ5155/01 User Manual
Page 2
Issue date 2013-05-13
Version: 2.0.4
12 NC: 9073 101 00818
EAN: 87 10895 78264 7
© 2013 Koninklijke Philips Electronics N.V.
All Rights reserved.
Specifications are subject to change without notice.
Trademarks are the property of Koninklijke Philips
Electronics N.V. or their respective owners.
Specifications
AZ5155/01
CD Soundmachine with Dynamic Bass Boost
MP3
Highlights
Video CD2.0 playback
Video CD2.0 playback with powerful playback
control function
Karaoke
The Karaoke feature on your DVD player provides
endless entertainment and maximum audio and
singing enjoyment.You can enhance your
performance by adding an ‘echo’ effect to your voice.
The key controls allows you to choose the optimal
key for your personal vocal range.
PAL/NTSC compatible
PAL/NTSC compatible
Incredible Surround™
Incredible Surround is an audio technology from
Philips that dramatically magnifies the sound field to
immerse you in the audio. Using state-of-the-art
electronic phase shifting, Incredible Surround mixes
sounds from left and right in such a way that it
expands the virtual distance between the two
speakers. This wider spread greatly enhances the
stereo effect and creates a more natural sound
dimension. Incredible Surround allows you to
experience total surround with greater depth and
width of sound, without the use of additional
speakers.
Dynamic Bass Boost
Dynamic Bass Boost maximizes your music
enjoyment by emphasizing the bass content of the
music throughout the range of volume settings -
from low to high – at the touch of a button! Bottom-
end bass frequencies usually get lost when the
volume is set at a low level. To counteract this,
Dynamic Bass Boost can be switched on to boost
bass levels, so you can enjoy consistent sound even
when you turn down the volume.
Bass Reflex Speaker System
Bass Reflex Speaker System delivers a deep bass
experience from a compact loudspeaker box system.
It differs from a conventional loudspeaker box
system in the addition of a bass pipe that is
acoustically aligned to the woofer to optimize the
low frequency roll-off of the system. The result is
deeper controlled bass and lower distortion. The
system works by resonating the air mass in the bass
pipe to vibrate like a conventional woofer.
Combined with the response of the woofer, the
system extends the overall low frequency sounds to
create a whole new dimension of deep bass.
CD Shuffle/Repeat
The "Shuffle/Repeat" function helps you to get rid of
the boredom of hearing your music played in the
same order all the time. After loading your favorite
songs to the player, all you have to do is to select one
of the modes - "Shuffle" or "Repeat" for your tunes
to be played in different modes order. Enjoy the
different and unique music experience every time
you hook up to your player.
CD synchro-start recording
CD to tape synchro-start recording
9 frames digest preview
9 frames digest preview for easy navigation
On Screen Display
On Screen Display for easy navigation
Sound
• Sound Enhancement: Dynamic Bass Boost,
Incredible Surround
• Output power (RMS): 2X4W
• Sound System: Stereo
• Loudspeaker types: Bass Reflex Speaker System
• Speaker diameter: 4"
• Volume Control: Volume Control rotary/encoder
Loudspeakers
• Built-in speakers: 2
• Finishing: Metal
• Loudspeaker types: Loudspeakers
Video Playback
• Disc Playback Modes: A-B Repeat, Fast Backward,
Fast Forward, OSD, Pause, PBC, Zoom, Slow
Motion, Introscan
• Playback Media: Video CD/SVCD
Audio Playback
• Playback Media: CD, CD-R, CD-RW, MP3-CD
• Loader Type: Top
• Programmable Tracks: 20
• Cassette Deck Technology: Mechanical
• Disc Playback Modes: Fast Forward/Backward,
Next/Previous Track Search, Repeat Play, Shuffle
Play
• Number of decks: 1
Audio Recording
• Recording Media: Tape
• Tape Recording Enhancement: CD Synchro Start
Recording
Tuner/Reception/Transmission
• Antenna: AM Antenna, FM Antenna
• Tuner Bands: FM, MW
Convenience
• Backlight: No
• Display Digits: 4
• Display Type: LCD
Connectivity
• Headphone: 3.5 mm
• Aux in: Karaoke
• Audio output: Stereo Audio (3.5 mm jack) 1x
• Video Output - Analog: Video (3.5mm jack) 1x
Accessories
• Included accessories: AC Power Cord, Audio/
Video cable, User Manual, Warranty certificate
• Remote control
Dimensions
• Packaging dimensions (W x H x D):
244 x 344 x 524 mm
• Product dimensions (W x H x D):
290 x 180 x 460 mm
• Weight: 4.7 kg
• Weight incl. Packaging: 5.9 kg
Power
• Battery type: LR20
• Battery voltage: 1.5 V
• Mains power
• Number of batteries: 8
•
