Peavey CS 1800G - Manual (Page 9)

SPECIFICATIONS
Output Power: (typical value)
1 2 0 V A C , 6 0
Stereo mode, both channels driven:
2 ohms, 1% THD: 900 W RMS per channel
4 ohms, 1% THD: 600 W RMS per channel
8 ohms, 1% THD: 350 W RMS per channel
Bridge mode. mono:
4 ohms, 1 1% THD: 1800 W RMS
8 ohms, 1 1% THD: 1200 W RMS
Rated Output Power:
1 2 0 V A C , 6 0 H z )
Stereo mode, both channels driven:
4 ohms, 20 Hz to 20 0.04% THD: 550 W RMS
per channel
8 ohms, 20 Hz to 20 0.04% THD: 300 W RMS
per channel
Power Bandwidth: (typical value)
Stereo mode, both channels driven
rated power, 4 ohms, THD: Hz to 40
Slew Rate: (typical value)
Stereo mode, each channel: 40 volts per
Bridge mode, mono: 80 volts per
Total Harmonic Distortion: (typical)
Stereo mode, both channels driven:
20 Hz to 20 4 ohm rated load: Less than 0.04%
Input Sensitivity Impedance:
Input attenuator set FCW:
rated output power, 4 ohms: V RMS (0
20 k ohms
Frequency Response: (typical value)
Stereo mode, both channels driven:
W RMS, 4 ohms: Hz to 40
-0.2 rated output, 4 ohms: 20 Hz to 20
Damping Factor: (typical value)
Stereo mode, 8 ohms, I Greater than 300
Hum Noise:
Stereo mode, below rated power, 4 ohms: 100
unweighted
Power Consumption:
Stereo mode, both channels driven:
rated output power, 4 ohms: 13 A 120 V AC,
6.8 A 230 V AC
Cooling System:
Dual 2 speed fans
Compression System:
Switchable with LED
Dimensions Weight:
Height: 3.50” (8.9 cm)
Width:
(48.3 cm)
Depth 17” (43.2 cm)
Weight 35 lbs. (15.9 kg)
Two Rack Space, Class BG, Dual Rail Design With
NSSER Topology
(NSSER: non-saturating series single emitter resistor)
Patent Pending.
to our efforts constant improvements,
specifications
9
