Part III Peformance Pads
71
QQTG0692
Pe
rfo
rma
nc
e
Pa
ds
Record a phrase
“User Bank” A, B and C are reserved for storing your original phrases.
• You can also copy phrases which are recorded in the SEQUENCER.
1. Press the PROGRAM MENUS button to turn it
on.
• The display looks similar to the following.
2. Select PERFORMANCE PADS.
• The display looks similar to the following.
3. Use the buttons to the left of the display to
select a RECORDING BANK.
• The display changes to the RECORD PAD
display.
• You can press the BANK NAMING button and
assign a name to the bank.
• If the BANK CLR button is pressed, all the
data in the bank is cleared (a confirmation dis-
play appears).
4. Use the buttons below the display to select the
pad number to record.
• The display changes to the PAD RECORD-
ING display.
• You can press the PAD NAMING button and
assign a name to the bank.
• To clear all the current data in the selected
pad, press the CLEAR THE PAD button, and
then press the YES button on the confirmation
display.
5. Use the MEAS
∧
and
∨
buttons specify the
number of measures in the phrase. Use the
TIME SIGNATURE
∧
and
∨
buttons to specify
the time signature of the phrase.
6. Press the OK button.
• For details about KEY SETTING, refer to page
111.
• For details about CHORD MODIFY CHANGE,
refer to page 109.
7. Select the part to record to.
• Press the button for PART 1 or PART 2.
• Two parts can be recorded (PAD 1–4).
• The display looks similar to the following.
8. Proceed to record.
• The recording procedure is the same as for
the COMPOSER. (Refer to page 104.)
• In the PLAY SETTING, if LOOP is set to OFF,
LOOP recording is not possible.
